AMX NXD-CA15 Dimension Manual

NXD-CV15
WALL
NXD-CA15
NOTICE: This drawing is the UNLESS OTHERWISE SPECIFIED:
property of AMX Corporation.
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
All information contained herein
XXX = .005
that is not generally known
TOLERANCE ON HOLE DIAMETERS:
UNDER .250 ú = +/- .005
shall be confidential except
.250 TO .500 = +.006 -.005
to the extent the information
OVER .500 = +.008 -.005
has been previously established.
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
ANGLES: +/- 1.0°
This drawing may not be copied,
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
reproduced, or used as the basis
ALL DIMENSIONS IN INCHES.
for manufacture or sale without
DO NOT SCALE THIS DRAWING.
written permission.
REVISIONS
REV ECN DESCRIPTION
4253 RELEASED TO PRODUCTION
A
B 4333 REVISED DRYWALL MOUNTING
REL APPR REL DATE REV APPR
DRAWN J.L. 10/1/02
DB
ENGR SERV JM 10/11/02
PICTORIAL
JSV 10/11/02 RDR
ENGINEER
NXD-CV15, AND NXD-CA15, MODERO 15"
MAS
PROD ENGR MAS 10/11/02
15" COLOR ACTIVE WALL
JS
MATL SUP MP 10/11/02
AK
QUALITY AVT 10/11/02 SIZE SCALE: DWG. NO.
D 1/2 95-2253-12
THIRD ANGLE
PROJECTION
95-2253-12_nxd-ca15_pictorial
DATE APPROVED
10/14/02
10/28/02
REV.
B
SHEET 1 OF 1
