Sportime 10' Net Assembly Instructions

December 2018
QwikNet Assembly Instructions
5
4
1
10' Net Assembly
Put together net base components as shown in the diagram above. Components are numbered for easy
assembly.
NOTE: DO NOT use the four component poles
These are used for only the 20' net option.
For Badminton Net:
Slide the net sleeves over each pole until the top of the sleeve reaches the top of the pole.
For Tennis Net:
1. Remove the bottom pole
2. Slide the net sleeves over each pole until the top of the sleeves reach the top of the poles.
10' Net Assembly
3
2
or the middle support unit
7
on each side of the QwikNet frame.
4
Sportime.com | 800-283-5700
3
2
8
1
Items 018208
5
4
1
, for the 10' net.
