Brinly SAT2-40BH1-P Owner's Manual

40" lawn aerator
Hide thumbs Also See for SAT2-40BH1-P:

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
4 0 " L A W N A E R A T O R
MODEL:
S AT 2 - 4 0 B H 1 - P
• Assembly
• Installation
• Operation
• Repair Parts
Visit us on the web!
www.brinly.com
English Manual
Call Customer Service, Toll-Free: 877-728-8224
Important: This manual contains information for the safety
of persons and property. Read it carefully before
assembly and operation of the equipment!
1
1019101-C

Advertisement

loading

Related Manuals for Brinly SAT2-40BH1-P

Summary of Contents for Brinly SAT2-40BH1-P

  • Page 1 • Operation • Repair Parts Call Customer Service, Toll-Free: 877-728-8224 Important: This manual contains information for the safety Visit us on the web! of persons and property. Read it carefully before www.brinly.com assembly and operation of the equipment! English Manual 1019101-C...

  • Page 2: Table Of Contents

    INTRODUCTION AND SAFETY ================================================================================================ CONGRATULATIONS on your new Brinly-Hardy Aerator! This accessory has been designed, engineered and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please do not hesitate to contact our knowledgeable customer service department toll-free at 1-877-728-8224.

  • Page 3: Safety

    SAFETY ================================================================================================ GENERAL NOTES (OPERATION) Caution should be taken when towing and/or using any attachment. This attachment combined with the weight distribution, turning radius, and speed of towing vehicle can result in severe injury or death to operator, damage to towing vehicle, and/or attachment if not used properly. Follow all towing safety precautions noted in the towing vehicle owner’s manual, including the following precautions: - Ensure the combined weight of the towing vehicle (tow vehicle weight + operator weight) is greater...
  • Page 4 Please call our Customer Service attachment may impair its function, safety and void the Department, Toll Free: 877-728-8224 warranty. or customerservice@brinly.com TOWING VEHICLE AND TOWING SAFELY - Know your towing vehicle controls and how to stop safely. READ YOUR TOWING VEHICLE OWNER’S MANUAL before operating.

  • Page 5: Component View And Reference List

    PARTS REFERENCE ================================================================================================ 14 + 14 + 13 + 13 + Ref # Part # Description R-892-16 Drawbar Clevis 1019088 Logo Decal 1018987-16 Tray Ref # Part # Description 1019212-16 Drawbar 1019244-16 End Panel 30M1600P Nut; Hex, 1/2” 45M1717P Washer; Flat, 1/2” 1019283-16 Axle Assembly 1018833...
  • Page 6 HARDWARE IDENTIFIER ================================================================================================ Illustrations on this page are to scale for faster identification of hardware during assembly. Do not return this product if you are missing parts. Washer; Thick Please Call: 1 (877) 728-8224 5/8” (x10) ... 1019390 Nut;...

  • Page 7: Assembly

    Illustrations on page 6 are to-scale. For faster identification of the hardware during assembly, simply lay the hardware on top of these illustrations. Additional info and videos are available on our website: brinly.com This QR code links directly to the Spike Aerator product page.
  • Page 8 ASSEMBLY ================================================================================================ Step 2 Install Drawbar Attach Drawbar brackets (29) to the tray (3) using the following as illustrated: x4 - 5/16” x 1” Hex Head Bolts (14) x4 - 5/16" Hex Lock Nuts (15) Attach the drawbars (4) to the drawbar brackets that were just attached.
  • Page 9 ASSEMBLY ================================================================================================ Step 3-A Slide the Axle (6) through the hole in the End Panel (5, right side). Add two 5/8" Thick, Flat Washers (16) to the axle. Step 3-B CAUTION: GLOVES ARE REQUIRED WHEN HANDLING AERATOR TINES. Tines have extremely sharp points.
  • Page 10 ASSEMBLY ================================================================================================ Step 3-C Position one or two washers (16 or 26) as needed to eliminate any side-to-side movement and push Axle Assembly (6) through hole in the left End Panel (5) as far as possible. See layout below. NOTE: Tines must not move from side to side inside opening of end panels. IF LOOSENESS EXISTS, use additional 5/8"...
  • Page 11 ASSEMBLY ================================================================================================ Step 4-B Slide the Handle Assembly (8) on the end of the Axle Assembly (6). Insert one 1/4” x 1-1/4” Hex Bolt (23) though the hole in the end of the Handle Assembly (8). Secure with 1/4” Hex Nut (24), as shown.
  • Page 12 ASSEMBLY ================================================================================================ Step 5-A While wearing gloves, carefully and gently flip the Spike Aerator over. Step 5-B IMPORTANT: Attaching the wheel without all of the proper hardware will cause the wheel to INSTALL FIRST WHEEL wobble. Insure all hardware is used, see Attach a wheel (9) to the wheel bar inset below.
  • Page 13 ASSEMBLY ================================================================================================ Step 5-C Attach the second wheel (9) to the Handle Assembly (6) using hardware in this order: • 1/2” x 3” Hex Bolt (19) • 1/2” Flat Washer (21) • Wheel (9) • 1/2” Flat Washer (21) • 1/2” Hex Nut (20) ( Handle Assembly ) •...

  • Page 14: Operation

    OPERATION ================================================================================================ CAUTION: Avoid damage to tines. Engage the transport wheels when crossing concrete or asphalt driveways and walkways. TRANSIT POSITION OPERATING POSITION - Pull FORWARD - Pull OUT on the on Handle Assembly (8). Handle Assembly (releasing from Transport - Pull out slightly &...
  • Page 15 Weight should be secured by rope, straps, or other suitable means to contain the weight in the tray. MODEL WEIGHT CAPACITY SAT2-40BH1-P 42 lbs. (Empty) - Weight tray maximum capacity = 150 pounds. 150 lbs. (Max Load) - Moderate soil moisture is 192 lbs.

  • Page 16: Maintenance

    MAINTENANCE / SPECIFICATIONS ================================================================================================ CAUTION: Avoid Injury! Keep body parts away from under drawbar. Do not disconnect aerator from the towing vehicle with weight on the tray. MAINTENANCE STORAGE CAUTION: AVOID INJURY! - After the first 30 minutes of - Store Aerator The Aerator Tines are very use check all fasteners for in low traffic...
  • Page 17 Please find your product serial number and model number, then contact our Customer Service department: In North America and Canada call Toll-Free: 877-728-8224 Chat online: www.brinly.com Email: customerservice@brinly.com NOTES English Manual 1019101-C...

  • Page 18: Warranty

    Hardy Co. During the period of the warranty, the exclusive remedy is repair or replacement of the product as set forth above. Brinly-Hardy Company • 3230 Industrial Parkway • Jeffersonville, IN 47130 • (877) 728-8224 • brinly.com English Manual 1019101-C...
