Page 1
*PRC-242 BH Push version not shown. Call Customer Service, Toll-Free: 877-728-8224 Important: This manual contains information for the safety Visit us on the web! of persons and property. Read it carefully before www.brinly.com assembly and operation of the equipment! English Manual 1020398-A...
INTRODUCTION AND SAFETY cONGRATULATIONS on your new Brinly-Hardy purchase! This accessory has been designed, engineered and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please do not hesitate to contact our knowledgeable customer service department toll-free at 1-877-728-8224.
HARDwARE IDENTIFIER DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. Illustrations on this page Please Call: 1 (877) 728-8224 are to scale for faster identification of hardware during assembly. Washer: Flat 5/8” (x4) ..Nut;...
ASSEMBLY Assembly Tip You can check out our step-by-step Lawn Roller assembly video by visiting our Brinly YouTube page, Brinly.com, or by scanning this QR code with your smartphone. wE RECOMMEND THE FOLLOwING STEPS FOR THE CARE OF YOUR ROLLER TO PREVENT...
Page 7
ASSEMBLY Step 1 Hardware Panel A Add a 5/8” flat washer (7) to the Roller Drum (2) as illustrated. Slide a square bearing (10) into the large square hole at the end of the Scraper Bar (3) and add to the Roller Drum. Add another 5/8”...
Page 8
ASSEMBLY NOTE: Do not tighten the lock nuts added on this step completely (until Assembly Step 4-A is complete). Step 3 Connecting the Frame Extension Bars Hardware Panel C center the Spacer (12) between the second hole of the Extension Bars (1) and run a 5/16”...
Page 9
ASSEMBLY PRT-362 BH, PRT-362S BH & PRT-482S BH: Attaching the Clevis If you are assembling PRC-242BH or PRC-242BH-A: Step 5 Skip Step 5 and continue Hardware Panel D to Assembly Step 6 Add the hitch pin (13) through remaining openings of the clevis (20) and secure with a Hitch Pin Cotter (14).
Page 10
ASSEMBLY Step 7 Adding the Roller Plug When installing the plug (9) please note the plug has an o-ring, ensure o-ring properly seats against the roller. A portion of the plug will extend from the roller, however, it will not interfere with the scraper bar (3).
Quality Results ..3 mph Drawbar and Bed. 1. Park towing vehicle safely using the parking brake (See towing vehicle PRC-242BH (-A) operator’s manual). 2. Align cart clevis (20) with towing Working Width ..24”...
Rider. Roller fully loaded with water weighs: • Occasionally check all moving parts for free movement and, if necessary, lubricate with oil. PRC-242BH & PRC-242BH-A = 270 lbs • Should rust develop, sand lightly and then paint PRT-362BH & PRT-362BH-A = 690 lbs area with enamel.
Additional info and videos are available on our website ( www.brinly.com ) OR scan one of the following QR codes: PRC-242BH PRT-362BH and PRC-242BH-A and PRT-362BH-A NOTE: Additional accesories are also available in our Parts Store online: shop.brinly.com...
MANUFACTURER’S LIMITED WARRANTY ROLLERS The limited warranty set forth below is given by Brinly-Hardy Company with respect to new merchandise purchased and used in the United States (its possessions and territories) and Canada. Brinly-Hardy company warrants the products listed below against to use this product.
