TABLE OF CONTENTS

X-CORE COMPONENTS ...................................................................4
MOUNTING THE CONTROLLER TO WALL ........................................8
CONNECTING VALVES AND TRANSFORMER ..................................9
ACTIVATING THE BATTERY ........................................................... 10
REPLACING THE BATTERY ............................................................ 10
CONNECTING A MASTER VALVE .................................................... 11
CONNECTING A PUMP START RELAY .............................................12
CONNECTING A HUNTER "CLIK" WEATHER SENSOR ....................13
Testing the Weather Sensor ........................................................13
Manually Bypassing the Weather Sensor ....................................13
CONNECTING A HUNTER SOLAR SYNC ET SENSOR .................. 14
Installing Solar Sync Sensor ....................................................... 14
Installing the Wireless Solar Sync® ............................................. 14
Solar Sync Settings .................................................................... 14
Region ..................................................................................15
Water Adjustment .................................................................16
Uninstalling a Solar Sync Sensor ................................................ 14
Calibration/Setup .......................................................................17
Solar Sync Delay Feature .............................................................18
CONNECTING A HUNTER REMOTE .................................................19
Connecting to a Hunter Remote (not included) ...........................19
To install the SmartPort connector ..............................................19
POWER FAILURES ......................................................................19
PROGRAMMING THE CONTROLLER .............................................20
Setting the Date and Time
Setting the Program Start Time(s)
Eliminating a Program Start Time ...............................................21
Setting Station Run Times
.....................................................21
.........................................21
......................................................21
Setting Days To Water ...........................................................21
Selecting Specific Days of the Week to Water .............................21
Selecting Odd or Even Days to Water ......................................... 22
Selecting Interval Watering
Setting Event Day(s) Off ............................................................. 22
Automatic Watering ...............................................................22
System Off ...........................................................................22
Programmable Rain Off .............................................................. 23
Seasonal Adjustment ............................................................ 23
Manually Run a Single Station
One-Touch Manual Start and Advance .......................................24
ADVANCED FEATURES .............................................................. 25
Programmable Sensor Override ................................................. 25
Test Program of All Stations ....................................................... 25
Hunter Quick Check® Diagnostics ............................................... 25
Easy Retrieve™ Program Memory ..............................................26
Programmable Delay Between Stations .....................................26
Resetting Controller / Clearing Controllers Memory ..................26
Clik Delay Instructions ................................................................ 27
Program Customization .............................................................28
Cycle and Soak ...........................................................................29
TROUBLESHOOTING GUIDE ..........................................................30
SPECIFICATIONS ........................................................................... 33
Operating Specifications ............................................................ 33
Electrical Specifications .............................................................. 33
Explanation of Symbols .............................................................. 33
CERTIFICATE OF CONFORMITY TO EUROPEAN DIRECTIVES ...34
.................................................22
............................................. 23
