- Page 1 SUNMI Technology ELECTRONIC SHELF LABEL BL202/BL203 BLA01/BLA02 BLA01/BLA02...
- Page 2 SUNMI Technology Implementation Process of SUNMI ELECTRONIC SHELF LABEL (ESL) Shanghai Sunmi Technology Co.,Ltd. Version: V1.1 Sep. 15, 2019 Page 1/16...
-
Page 3: Table Of Contents
3.3 Labels and Accessories ......................8 4 Software Operation ........................... 8 4.1 SUNMI digital store ........................ 9 4.1.1 Register an account in SUNMI digital store ..............9 4.1.2 Set up docking of product information ............... 9 4.1.3 Template design ......................11 4.2 SUNMI ESL APP ........................ -
Page 4: Revision History
SUNMI Technology Revision History Issued Date Revised Contents Version 2019-07-28 Draft V1.0 2019-09-15 English version V1.1 Page 3/16... -
Page 5: Preliminary Work
It takes about two weeks for product information docking. The general process of product information docking is as follows: 1. SUNMI, the software partner shall discuss docking requirements and release technical documents; 2. Confirm the docking plan and schedule the project;... -
Page 6: Access Point
3.2 Access Point 3.2.1 Introduction The access point (AP) for SUNMI smart ESLs is used to connect ESL equipment with SUNMI digital store. The image and the instruction emitted by the digital store server are transmitted to the wireless access point through the Ethernet, and the access point is further distributed to the ESL through the wireless communication of the 2.4 G frequency band, so that the cloud change price and... -
Page 7: Base Installation
3.2.2 Base Installation 3.2.2.1 Power Supply Mode SUNMI wireless access point for smart ESLs supports power adapter and PoE power supply, which power supply mode needs to be determined by in-store environment and installation mode. The power adapter line is 2 meters long. Use the plug board if it is not long enough, while strictly forbid to extend the power cord by yourself. -
Page 8: Access Point Configuration
The installation distance between access points can be adjusted accordingly. 3.2.3 Access Point Configuration After all ESL access points are installed, it is necessary to use SUNMI assistant APP to configure each access point, including the Internet access mode and name of each access point. -
Page 9: Labels And Accessories
4 Software Operation Software configuration and usage include operations on the SUNMI digital store website and on the SUNMI ESL APP of PDA. In SUNMI digital store, you need to complete: 1. -
Page 10: Sunmi Digital Store
SUNMI Technology 4.1 SUNMI digital store The operations of SUNMI digital store need to be complete before the deployment of equipment installation. 4.1.1 Register an account in SUNMI digital store Visit website store.sunmi.com through Chrome, Firefox, QQ browser and 360 browser on computer to register account. - Page 11 After setting up ERP docking, the product library of the digital store will get all the product information from the ERP through the API interface, and it will synchronize to the SUNMI digital store after each modification in ERP, and then synchronize to the ESL.
-
Page 12: Template Design
Suggest to complete the validation of template in advance. 4.2 SUNMI ESL APP The operations of SUNMI ESL APP are under equipments deployment. Please acquire SUNMI ESL APP in SUNMI APP Store, and the APP is functioning in SUNMI L2 only. 4.2.1 Access point configuration... - Page 13 SUNMI Technology 2. Go to the APP system page, click [AP management > Add AP], then start searching access point signal with l2. In order to ensure that the signal strength of the access point is strong enough to be connected by L2, it is necessary to search as close as possible to the access point.
-
Page 14: Esl And Product Binding
SUNMI Technology 3. Select the access point that needs to be added (according to the signal strength or MAC address, the scanned MAC address is the same as the MAC address on the bottom nameplate of the access point) to enter the process of the access point adding and configuring. - Page 15 [Select ESL] can be achieved through the bar code on the L2 ESL (the bar code is the unique identified ID), or through NFC by close L2 to the ESL to obtain the ID. SUNMI ESL support NFC, which can obtain the ESL ID through NFC on the PDA, or reset the ESL device.
-
Page 16: Esl Unbinding
SUNMI Technology After completing the binding of all products and ESL, return to the home page of the SUNMI ESL APP. When the number of ESLs to be pushed becomes 0, that means all the ESLs are completed and the ESL system is deployed for the first time. -
Page 17: Product Inquiry
SUNMI Technology 4.2.4 Product inquiry Inquire through the product number / name / bar code, and the bar code of the product binding ESL. Enter the product details page to see the product information, as well as the ESL bound to the product, click on the flash lamp to allow the ESL flashing immediately.
