Highcross ECM-IR4B Quick Reference Manual

ECM-IR4B is a universal multifunctional IR-control module, designed
to control audio / video systems, air conditioners and any other
IR-controlled appliances. The module has intelligent IR-learning to
parse and analyse unique and repeating sequences.
The control, data exchange and configuration are all handled via
TCP/IP protocol.
COMMON DATA
Network interface
Supply voltage range
Consumption current
Operating temperature
Operating humidity
Enclosure
Dimensions (HWD)
Weight
Supported data exchange
protocols

RECEIVING OF IR CODES

Number of ports to receive
IR commands
IR receiver carrier frequency 38 kHz

FRONT PANEL COMPONENTS

IR 1–4 Activity indicators of ports 1–4
reset Multifunctional button (reboot, reset, bootloader)
link Ethernet link and activity indicator
Indicates power status and connection to control-
status
lers

REAR PANEL COMPONENTS

LAN Ethernet network RJ-45 socket (PoE)
1–4 mini-jack (3.5 mm) sockets to plug IR emitters
–
mini-Phoenix connectors to connect IR emitters
1...4 +/
PWR Power terminal (12–24 VDC)
ECM-IR4B
Infrared Control Module
Quick Reference Guide (revision 1.60 for H/W Rev.C)

OVERVIEW

SPECIFICATIONS

Ethernet (10/100)
12–24 VDC via power terminals
48 VDC via PoE port
120 mA @ 12 VDC
-20° C to 45° C
-5° F to 115° F
5 to 80% RH
non-condensing
Metal with black matte finish
34 mm x 84 mm x 109 mm
1.34" x 3.30" x 4.30"
190 g / 0.42 lbs
NetString
ModBus TCP
ModBus RTU over TCP
5

DEVICE CONTROL COMPONENTS

The device features:
• 4 ports to connect external IR emitters and receivers
• built-in high-power IR-blaster (supported on port #4)
• built-in IR receivers to receive IR commands and to capture
IR codes from device's remote controls
Number of ports to transmit IR
commands
Output power of ports for
external IR emitters
Power of built-in IR blaster
IR carrier frequency
Supported file formats of IR
commands
Maximum number of commands
per IR file
Maximum length of IR command
(unique and repeating parts)
IR carrier frequency to capture
commands from IR remote
Maximum length of IR command
(unique and repeating parts)
Output format of captured IR
code
©
HighCross Ltd.

TRANSMISSION OF IR CODES

4
5 mA, 25 mA, 30 mA
200 mA (4 IR emitters)
20 – 500 kHz
.phex – ProntoHex format
.IRL – AMX format
.IR – Crestron format
255
1000 intervals
(500 On/Off pairs)

CAPTURING OF IR CODES

20 – 60 kHz
2000 intervals
ProntoHex
REAR VIEW
FRONT VIEW
