AMX AXD-EL Plus Dimensional Drawing

NOTICE: This drawing is the UNLESS OTHERWISE SPECIFIED:
property of AMX Corporation.
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
All information contained herein
XXX = .005
that is not generally known
TOLERANCE ON HOLE DIAMETERS:
shall be confidential except UNDER .250 ú = +/- .005
.250 TO .500 = +.006 -.005
to the extent the information
OVER .500 = +.008 -.005
has been previously established.
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
ANGLES: +/- 1.0°
This drawing may not be copied,
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
reproduced, or used as the basis
ALL DIMENSIONS IN INCHES.
for manufacture or sale without
DO NOT SCALE THIS DRAWING.
written permission.
REVISIONS
REV ECN DESCRIPTION
ADDED METRIC DIMENSIONS
A
B 3076 RESURRECTION
REL APPR REL DATE REV APPR
DRAWN RDR 4/15/92
TM
ENGR SERV
ENGINEER
PICTORIAL
PROD ENGR AXD-EL+ (/PB)
(WITH LOW PROFILE BACKBOX)
MATL SUP
SIZE SCALE DWG. NO.
QUALITY
95-0797-06
C FULL
THIRD ANGLE
PROJECTION
95-079706
DATE APPROVED
12/22/93
11/26/01
REV.
B
1 OF 1
SHEET
