Thank you for purchasing this Devon bunk bed. Please read the instructions carefully before use to ensure safe
and satisfactory operation of this product.
Please check the pack contents before attempting to assemble this product. A full checklist of components is
This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE CARE WHEN
LIFTING to avoid personal injury and (or) damage to the product.
This product takes approximately 90 MINUTES to assemble with 2 PEOPLE.
If you require any additional information or have any issues with this product please call the John Lewis
Helpline on 01244 689949 or email mail@fwgroup-uk.com.
Devon Bunk Bed
SMALL PARTS which should be KEPT AWAY FROM YOUNG CHILDREN.
Stock code 803/61601, 803/61701, 803/61801
For product support or spare parts
please call the John Lewis Helpline;
T: 01244 689949
E: mail@fwgroup-uk.com
Advertisement
Related Manuals for John Lewis Devon 803/61601
Summary of Contents for John Lewis Devon 803/61601
- Page 1 This product takes approximately 90 MINUTES to assemble with 2 PEOPLE. SMALL PARTS which should be KEPT AWAY FROM YOUNG CHILDREN. If you require any additional information or have any issues with this product please call the John Lewis Helpline on 01244 689949 or email mail@fwgroup-uk.com.
- Page 3 7 x 50mm Ladder steps - 1 pc Ladder steps Ladder - 2 pcs Ladder right left side side - 1pc - 1pc...
- Page 4 Step 1 Insert dowels (C) in to the pre drilled holes on the side rails 4 and 5 and side panels 6, 7, 8, 9 and ladder steps 13 and 14 as shown below. Step 2 Attach ladder right side (11), ladder left side (12) and ladder steps (13) and (14) together using screw (H) tighten using a philips head screw driver.
- Page 5 Step 3 Attach side rails (4 and 5) and side panels (6 and 7) to headboard (1) using barrel nut (E) and bolts (B), as shown below. Repeat this process to attach side rails (4 and 5) to headbaord (3), as shown below. Tighten using allen key (A).
- Page 6 Step 4 Following on from step 3, attach headboard (2) to side rails (4 and 5) and side panels (6 and 7) as shown. Tighten using a philips head screw driver. Step 5 Starting at 1 end of the bed, scure the rst tted slat into place using screws (G). Next, secure the tted slat to the other end of the bed using screws (G) ensuring there are no gaps between the slats and headboards.
- Page 7 Step 6 Insert dowels (I) in to the pre drilled holes on the headbaords (3), place the upper bed as shown below. Step 7 Secure in to place using screw (G) in to the pre drilled holes as shown below. Tighten using a philips head screw driver.
- Page 8 Step 8 Attach the ladder on to the side rails (5) using screw (F), in to the pre drilled holes fome the side of side rails (5) as shown below. Tighten using allen key (A). Step 9 Attach the side panels (8 and 9) on to the headboard (1) and ladder. Use barrel nuts (E) and bolt (B) to secure the headboard (1) to side panels (9 and 10), tighten using allen key (A).
- Page 9 Step 10 Attach the vertical support rail (10) in to upper bunk sides, using screw (D) in to the pre drilled holes as shown below. Tighten using a philips head screw driver.
- Page 10 Wood Furniture ray’ which can appear on oak furniture is a mark of good quality timber - these are just characterisitics of the natural beauty of the wood. Some furniture is also deliberately aged and rustic. drawer fronts by the way the slivers are arranged. All timber surfaces will change colour and mellow over time.
