GENERAL
AC Power:
100-240 VAC single phase, 47-63 Hz
Power Consumption (max):
51 Watts per enclosure
Operational Temperature:
32° to 110° F (0° to 43° C)
Humidity:
0 to 90% non-condensing
Enclosure Dimensions:
10.4" (26.4 cm) depth
17.4" (44.2 cm) width w/o rack ears
18.8 (47.7 cm) width w/ rack ears
Height:
5.2 (13.0 cm) 3 RU
Weight:
Appx. 12 lbs (5.4 kg) per enclosure
Approvals:
CE, ETL, cETL, FCC
STANDARD AUDIO
Input Level (max):
+27 dBu, balanced
Input Impedance:
18 kΩ
Output Level (max):
+27 dBu, balanced
50 Ω
Output Impedance:
Frequency Response:
<+/- 0.1 dB (20 Hz to 20 kHz)
THD + Noise:
<0.02% (20 Hz to 20 kHz, Vin = -6 dBu
to +26.6 dBu), no volume control
<0.1% (20 Hz to 20 kHz, Vin = -10 dBu
to +20 dBu), with volume control
Signal to Noise Ratio:
>105 dB (20 Hz to 20 kHz, Vin = +20 dBu),
no volume control
>80 dB (20 Hz to 20 kHz, Vin = +10 dBu),
with volume control
Crosstalk:
<-90 dB (1 kHz, Vin = +14 dBu),
no volume control
<-110 dB (20 Hz to 20 kHz , Vin = +14 dBu),
with volume control
Input Volume Adj. Range:
+10 dB to -10 dB
Output Volume Adj. Range:
+10 dB to -70 dB
Connectors:
5T
DIGITAL AUDIO (TosLink, S/PDIF)
Resolution:
16 to 24 bit
Sample Rate:
32 to 96kHz
Connectors:
TosLink, S/PDIF
WIDEBAND VIDEO
Input Level (max):
+/- 1.5 Volts
75 Ω
Input Impedance:
Output Level (max):
+/- 1.5 Volts
75 Ω
Output Impedance:
Frequency Response:
300 MHz or better (+/- 3dB)
Crosstalk:
<-60 dB (f = 5 MHz)
Signal to Noise Ratio:
>65 dB (Vin = 0.7V, 100% IRE)
HV Sync Input:
+/- 5 Volts
HV Sync Output:
+/- 5 Volts
HV Frequency:
50 MHz or better (+/- 3dB)
HV Crosstalk:
<-70dB @ 5MHz
Connectors:
BNC, RCA
