ACCESSORIES
2
NUT REPLACEMENT KIT
P/N 500208.
To replace stripped or
damaged insert nuts in
engine base.
BLADE BC2401
P/N 500210.
Original Equipment Blade
for replacement.
BELT TRACTION DRIVE
P/N 500119.
Traction Drive Belt
for BC2401
BELT BLADE DRIVE
P/N 500237.
Blade Drive Belt
for BC2401
BLADE HIGH LIFT
BC2401
P/N 500102.
Optional blade for
replacement
The Powerful BC2401 SELF-PROPELLED BRUSH CUTTER
Operator Owner's Manual
3
ENGINE: H.P.
ENGINE: TYPE
ENGINE MODEL NO:
ENGINE: FUEL CAP.
ENGINE: OIL CAP.
WEIGHT: UNIT
WEIGHT: SHIPPING
ENGINE WEIGHT:
MAX. OPERATING SLOPE
UNIT SIZE:
OVERALL LENGTH: 82.5"(2.09 m)
Part No. 500264
T h a n k Y o u f o r S e l e c t i n g
BC2401IC, BC2401H, BC2401HE

Specifications

BC2401IC
10.5 (7.83 kW)
B&S
28B702118-E1
3.0 qt. (2.84 L)
1.34 qt. (1.41 L)
282# (128.5 kg)
310# (141.3 kg)
66.0# (30.0 kg)
°
15
OVERALL WIDTH 32.0" (0.81m)
Page 1 of 12
BC2401H
BC2401HE
11 (8.20 kW)
11 (8.20 kW)
HONDA
HONDA
GXV340K1DX3
GXV340K1DE33
2.3 qt. (2.18 L)
2.3 qt. (2.18 L)
1.20 qt. (1.13 L)
1.20 qt. (1.13 L)
278# (126.1 kg)
282# (127.9 kg)
306# (138.8 kg)
310# (140.6 kg)
70.5# (32.0 kg)
72.5# (32.9 kg)
°
°
20
20
OVERALL HEIGHT43" (1.09m)
Form No. F101001A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BC2401H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Billy Goat BC2401H

  • Page 1: Specifications

    T h a n k Y o u f o r S e l e c t i n g The Powerful BC2401 SELF-PROPELLED BRUSH CUTTER Operator Owner's Manual BC2401IC, BC2401H, BC2401HE ENGINE: H.P. ENGINE: TYPE ENGINE MODEL NO: ENGINE: FUEL CAP.
  • Page 2: Table Of Contents

    IN THE INTEREST OF SAFETY BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S MANUAL & ENGINE MANUAL.” THIS SYMBOL MEANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. WARNING: The Engine Exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
  • Page 3: General Safety

    PUT OIL IN ENGINE BEFORE STARTING. DISCONNECT SPARK PLUG WIRE BEFORE ASSEMBLING UNIT. Your Billy Goat Brush Cutter is shipped from the factory in one carton, completely assembled except for the upper handle, and front guard bar. PACKING CHECKLIST These items should be included in your carton.
  • Page 4: Throttle Control

    Ty Wrap 900407 Qty: (4) INSTRUCTION LABELS These labels should be included on your Brush Cutter. If any of these labels are damaged, replace them before putting this equipment into operation. Item and part numbers are given to help in ordering replace- ment labels..
  • Page 5: Operation

    Danger, the clog may contain sharp materials. Reconnect spark plug wire. BLADE CLUTCH The Brush Cutter blade clutch is controlled by an operator presence control. To engage the blade, depress the operator's left hand control lever against operator's handle. The blade is disengaged by releasing this lever.(See Fig.
  • Page 6: Parts Drawing & List

    PARTS DRAWING BC2401HE, BC2401H, BC2401IC Part No. 500264 Form No. F101001A Page 6 of 12...
  • Page 7 SCREWCAP 5/16-18 X 1" Screw Cap 5/16 - 18 x 2 3/4 Bolt Carraige 5/16 - 18 x 3/4 Washer Flat 1/2" Pin Cotter 3/32 x 3/4" Part No. 500264 BC2401HE BC2401H Part No Part No 500239 500239 500266 500266...
  • Page 8 500299 500303 500302 500297 500298 400424 810736 900327 500202 890301 890254 500168 500279 500176 500177 Page 8 of 12 Qty. BC2401H Qty. BC2401IC Qty. Part No. Part No. 500114 500114 *8160003 *8160003 800888 800888 *8041032 *8041032 *8142002 *8142002 *8160002 *8160002...
  • Page 9: Cutting Height Adjustment

    16.3 PROPULSION This Brush Cutter is self-propelled, and is controlled by an operator presence control. To engage the wheel drive, lift the operator's right hand control lever against operator's handle. The drive is disengaged by releasing this lever.(See Fig. 1.2)
  • Page 10: Maintenance

    MAINTENANCE Use only a qualified mechanic for any adjustments, disassembly or any kind of repair . WARNING: TO AVOID PERSONAL INJURY, ALWAYS TURN MACHINE OFF, MAKE SURE ALL MOVING PARTS COME TO A COMPLETE STOP. DISCONNECT SPARK PLUG WIRE BEFORE SERVICING UNIT. RECONNECT SPARK PLUG WIRE, AND ALL GUARDS BEFORE START- ING ENGINE.
  • Page 11: Blade Drive Belt Tension Adjustment

    MAINTENANCE continued 6. With the guides loose slip the blade drive belt(29) out of the groove on the drive pulley and down past the pulley. Note: It is necessary to remove the transaxle drive belt(10) from its groove to allow removal of the blade drive belt.
  • Page 12: Clutch Adjustment

    MAINTENANCE continued 17.3 CLUTCH ADJUSTMENT Clutch/Brake Adjustment: As the clutch/brake wears, adjustments may be required to maintain proper control cable tension, and clutch engagement. If the clutch/brake begins slipping or squealing during normal operation it may require an adjustment to increase the clutch cable tension.
