Qubic 50, 60 & 80 Cabinets

Apex 50, 60, 80 & 100

Thank you for purchasing this HiB product.

Please read through these instructions carefully and refer back to them during installation to ensure that

your product is fitted safely and that it retains its high quality finish.

Please retain this leaflet for future reference.

Before drilling, ensure there are no hidden cables or pipes in the wall. Ensure the domestic electrical

mains supply to which the cabinet is being connected is turned off.

Please Note You may need to remove the door / doors to aid installation.

This can be done by unclipping the hinges. (There is a release catch at the

back of the hinge). DO NOT FIT SHELVES AT THIS STAGE.

Please Note These products must be installed with a minimum distance of 150mm

between the infra-red sensor switch and any surface or object to ensure correct

operation of the sensor.

Qubic 50:

Art No. 46400

Apex 50:

Art No. 47000

Qubic 60 & 80:

Art No. 46500 & 46600

Apex 60, 80 & 100:

Art No. 47100, 47200 & 47300

#02 007 R161103

Ver No.

Min. 150mm

2.0 Jan 2017

Need help?

Do you have a question about the Qubic 50 and is the answer not in the manual?

Page 1 Qubic 50, 60 & 80 Cabinets Apex 50, 60, 80 & 100 Qubic 50: Qubic 60 & 80: Art No. 46400 Art No. 46500 & 46600 Apex 60, 80 & 100: Apex 50: Art No. 47100, 47200 & 47300 Art No. 47000 Thank you for purchasing this HiB product.
Page 2 REAR VIEW Mounting Points Location of internal xing hole (SINGLE DOOR) Location of internal Angle Adjustment xing hole (DOUBLE DOOR) Claw In/Out Claw In/Out Adjustment Adjustment Fixing Preparation (Fig A) Fixing Brackets (Fig B) Hanger Adjustment (Fig C) Wall Hung Installation to avoid cracking.
Page 3 Make sure that or(s) left/right the cabinet is held firmly so that it is not pushed off the wall. After a few uses, stiffness will ease and the socket will function as normal. Door Adjustment (Fig D) hib.co.uk...
Page 4 ©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try and make sure they are as accurate as possible. In the interest of continuous product development, HiB reserves the right to alter specifications as necessary. E & OE.
