MUNBYN IMC08 Maintenance Manual

Hide thumbs Also See for IMC08:
Table of Contents

Advertisement

Quick Links

Download this manual
IMC08 Banknote Counter
Maintenance Manual
Document Name:
IMC08 Maintenance Manual-1.01.docx
Prepared by:
Reviewed by:
Approved by:
1.01
Name
Byron Zhong
Signature
Date

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMC08 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MUNBYN IMC08

Summary of Contents for MUNBYN IMC08

  • Page 1 IMC08 Banknote Counter Maintenance Manual 1.01 Document Name: IMC08 Maintenance Manual-1.01.docx Name Signature Date Prepared by: Byron Zhong Reviewed by: Approved by:...

  • Page 2: Version History

    Version History Date Changes Version • Initial Version 2021-02-23 Byron Zhong 1.00 • Update Error Analysis 2021-06-18 James Hu 1.01 • • Page2of17 IMC08 Maintenance Manual Version 1.01...

  • Page 3: Table Of Contents

    Hopper Sensor Error ....................10 3.3.2. Stacker Sensor Error ....................10 3.3.3. Counting Sensor Error ....................10 3.4. Feeding Gap Calibration ....................11 3.5. CIS Calibration........................13 3.6. Back to Default Setting ..................... 15 Page3of17 IMC08 Maintenance Manual Version 1.01...

  • Page 4: Overview

    1.0. Overview Thank you for purchasing our banknote counters IMC08. After starting the machine, it will go on self-check automatically. If the preset window shows the error code or tell you to clean the sensors, generally speaking, it is because of dust on the surface or sensor blocked by notes.

  • Page 5: Cleaning The Machine

    Reject Pocket Stacker Sensor Figure 2-1 The Sensors in Stacker and Reject Pocket Clean the Internal Sensors 2.3. Pull the handle of back cover. The Handle of Back Cover Figure 2-2 Handle of Back Cover Page5of17 IMC08 Maintenance Manual Version 1.01...
  • Page 6 Wheels Figure 2-5 Upper Sensor Note: For the CIS sensors, it is recommended to used cleaning cloth to clean them, as shown in the following figures. Close the cover and finish the machine cleaning. Page6of17 IMC08 Maintenance Manual Version 1.01...

  • Page 7: Error Analysis

    Collect data of the banknote. In the process of using the IMC08, the IMC08 may show abnormal state and display the error codes on the screen. The description of the error codes and the related handling method is shown in table 3-1.

  • Page 8: Bill Stuck In The Feeding Port (Ps1 Error)

    4.1. 4) Other abnormal operation or there is unknown thing inside the IMC08.If something inside the IMC08, you need to open the back cover to check, and clean the internal sensors.

  • Page 9: Bill Stuck In The Inside Of Machine (Ps3R Error)

    ALWAYS ENSURE MACHINE IS OFF BEFORE PUTTING HANDS/FINGERS IN THE INSIDE OF MACHINE. 3.2.3. Bill stuck in the reject pocket (TD Error) When a bill is stuck in the reject pocket of IMC08, a TD Error will appear. Please follow the method below to remove the banknote. Page9of17 IMC08 Maintenance Manual Version 1.01...

  • Page 10: Sensor Errors

    The IMC08 banknote counter will take a few seconds to conduct a self-check with spinning the counting wheels after power on. The IMC08 will check the sensors, the following errors may happen if the sensors have been blocked or damaged.

  • Page 11: Feeding Gap Calibration

    To fine tune the feeding gap, do the following: 1) Turn off the auto counting feature. 2) Insert one banknote into the gap between the rollers to check if the banknote can be inserted smoothly, as shown in the following. Page11of17 IMC08 Maintenance Manual Version 1.01...
  • Page 12 Figure 3-12 One Coin to Rotate the Screw The IMC08 needs different gaps for different currencies, but otherwise should stay consistent. Having the correct feeding gap adjusted will ensure smooth operation as well as a trouble-free experience. You may need to do some trial and error before getting it perfectly smooth.

  • Page 13: Cis Calibration

    Figure 3-13 Main Menu Figure 3-14 Service Menu 2) Click the “CIS Calibration” option, shown below: Figure 3-15 CIS Calibration Interface 3) Open the back cover to clean the CIS sensors with a lint-free cleaning cloth. Page13of17 IMC08 Maintenance Manual Version 1.01...
  • Page 14 4) Using the included CIS calibration sheet (white paper), place inside as seen below, and close the back covers. Figure 3-18 Place the CIS Calibration Paper 5) Start CIS calibration by pressing the “RESTART” button. Page14of17 IMC08 Maintenance Manual Version 1.01...

  • Page 15: Back To Default Setting

    Figure 3-20 Service Menu Figure 3-21 Default Setting Interface 2) After pressing start, the IMC08 will reset all the changed settings beforesettings to factory default. Figure 3-22 Default Setting Guide 3) The processing wheels and rollers in the IMC08 will run for a while.
  • Page 16 Figure 3-23 Touch the Hopper Sensor Page16of17 IMC08 Maintenance Manual Version 1.01...
  • Page 17 Scan the QR code for Facebook online chat Contact us Email: support@munbyn.com Whatsapp: +86-17817881067 If you meet any problem during using the IMC08, please contact us. Page17of17 IMC08 Maintenance Manual Version 1.01...
