Note: Marquees are intended for events and other arrangements and are as such only meant for short term temporary assembly and the following disassembly. Dancover warranty applies only to the normal use of the Product, normal wear and tear excepted, in accordance with written use instructions or manual.
Assembly Procedures ground condition is suitable. roof tubes to them accordingly. 3. Make each group of frame straight and assemble the roof purlins and horizontal walls in turn. Make sure that all screws are tightened enough. 4. Assemble the cross tubes in front and back wall including the tensioning tube for covers at the bottom.
Page 4
Assembly Illustration For “user friendly” assembly we have identified each individual component with our partcode number as indicated in the part list. Please refer to the part code number and drawings to ensure problem free assembly.
Page 5
Part List (W6xL12xSidewall3.5xH5.5M) with 3.5x3.5M machining door Part No. Description Qty(pcs) Curved Roof Tube (top) at two ends &tube size:1148mm Curved Roof Tube (top) in the middle &tube size:1148mm Straight Roof Tube at two ends &tube size:1787mm Straight Roof Tube in the middle &tube size:1787mm Curved Roof Tube (side) at two ends &short tube:660mm,long tube:1400mm Curved Roof Tube (side) in the middle &short tube:660mm,long tube:1400 mm Sidewall(in the middle) with base flange &tube size:2100mm...
Page 6
W 6X L12 XS3. 5XH 5.5M (wi th3 . 5 X 3 . 5 m a c h i n i n g d o o r ) P ar t N o . D ia g ra m Qt y Di a gr a m Q ty P a rt No .
Page 7
6x12x3.5x5.5M Schematic drawing of placement for base flange...
Page 9
6x12x3.5x5.5M Frame installation procedure And connection hint 7-8 M14x70 bolt with nut slant supporting tube M12x50 bolt with nut M12x50 bolt with nut 1 1 B...
Page 10
Frame connection hint M14x30 bolt with nut...
Page 11
6x12x3.5x5.5M Illustration for installation and tensioning both sides of roof cover...
Page 12
Hint of tensioning front and rear folds Pls put the ropes in the roof cover pocket throughthe rings and pull hard the ropes. At the same time pls tidy rumple on the folds. Gradually,when the cover is well on the frame,pls knot the ropes on the rings as below show.
Page 13
Illustration for installation of front cover. As below shows edges of front cover are secured to the frame by ropes.
Page 14
As below shows the both sides and top Part of rear cover are tightened to the frame by rope. The bottom part of rear cover is fastened to the tensioning tube by rope as below shows. 9A-2 M14x30 bolt with nut 9A-1 1 1A 9A-3...
