American Megatrends StorTrends 1300i Specifications

1U IP-SAN and NAS Storage Appliance
HIgHlIgHTS
> 1.0, 2.0, 3.0 or 4.0 TB IP-SAN & NAS storage
appliance
>
4 Hot-swappable SATA Drives
>
Enhanced Reliability with Redundant
450W Power Supply and Smart UPS
Support
> Volume Replication
- Synchronous
- Asynchronous
- Snapshot-assisted
- WAN-Optimization Data Services
(WDS) featuring Deduplication,
Encryption, and Link Acceleration
>
Advanced Snapshot
- Redirect on Write (ROW)
- Up to 1022 snapshots (R/O and R/W) per
volume
- Up to 2048 snapshots per box
- Snapshot scheduling for SAN & NAS
- Rollback from any snapshot
- Random snapshot deletion
>
Software RAID support: RAID levels 0, 1, 5
> Online capacity expansion, RAID level
migration
>
High Availability (HA) grouping
- load Balancing
- Active / Active Configuration
> Network Teaming
T
tor rends
w ww.am i.c om
The StorTrends® 1300i is an affordable 1U, rack-mount storage appliance
that offers support for both block and file data. It merges Ethernet-based
Storage Area Networks (IP-SAN) and Network Attached Storage (NAS) on a
single storage platform.
The StorTrends 1300i supports iSCSI, enabling block applications like
Microsoft® Exchange and Oracle® to be deployed or stored on the same
server as traditional file services and storage. The StorTrends 1300i is designed
with performance in mind, and includes features for enterprise-level storage
management such as advanced snapshots, synchronous and asynchronous
volume replication, and failover in a high availability configuration.
StorTrends® products
true enterprise-level features to
departmental and small- to mid-size
business (SMB) users. They merge IP-
SAN and NAS functionality into one
cost-effective, scalable, and easily
deployable storage appliance.
The StorTrends 1300i offers four
hot-swappable drive bays
advanced SATA support, as well
as highly distinguishing software
features. Dual-dialect StorTrends®
iTX software enables transfer of both
block and file data over the existing
Ethernet network, along with a host
of advanced features that until now
only existed in systems costing many
times more than the StorTrends
1300i.
The Volume replication feature
of the StorTrends 1300i allows data
to be stored on multiple StorTrends
appliances at multiple sites, for high
availability and disaster recovery in
the event of a catastrophe.
StorTrends' Advanced Snapshot
capability features Redirect-on-Write
(ROW) technology with near-zero
degradation when writing or rolling
back snapshots. Administrators can
schedule up to 1,022 read-write
and 1,022 read-only snapshots per
© 2008 American Megatrends Inc. - Specifications subject to change without notice
provide volume, and up to 2,048 snapshots
per box. A maximum of 64 volumes
per appliance is supported.
Asynchronous
bundles I/Os and sends them to the
remote server, boosting network
utilization efficiency and reducing
bandwidth cost.
with with the revolutionary WDS feature
included in the
replication module, the system take
advantage of a "triple-threat" of data
deduplication, data encryption and
link optimization to reduce data
transmission and bandwidth usage
by several factors over conventional
replication speeds.
For improved
disaster prevention, the StorTrends
1300i features a redundant 450W
power supply, as well as Smart UPS
support, which allows the appliance
to seamlessly switch over to UPS
power in the event of a power failure
and initiate a graceful shutdown.
StorTrends
be managed by the integrated
ManageTrends™
which provides
management of multiple StorTrends
appliances deployed
network.
Data Sheet
12 01 2008
replication
When combined
asynchronous
reliability and
appliances can
web-based gUI,
discovery and
across the
