EzLogger Pro SERIES USER MANUAL
EzLogger Pro
Smart Data Logger
Ver 1.3
2021/04/15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EzLogger Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Goodwe EzLogger Pro

Summary of Contents for Goodwe EzLogger Pro

  • Page 1 340-00027-03 Company Website Company WeChat EzLogger Pro SERIES USER MANUAL GOODWE (China) GOODWE (Australia) No. 90 Zijin Rd., New District, sales@goodwe.com.cn Suzhou, China service.au@goodwe.com.cn 215001 Tel: +86(0)512 6958 2201 sales@goodwe.com service@goodwe.com EzLogger Pro GOODWE (Netherlands) GOODWE (United Kingdom) enquiries@goodwe.co.uk sales@goodwe.com.cn Smart Data Logger service@goodwe.co.uk...

  • Page 2: Table Of Contents

    4.4 Connection to the Computer .................. 4.5 Connection to the Ripple Control Receiver ............4.6 Connection to DRED ....................Chapter V: LAN EzLogger Pro Data Upload and Function Configuration ..17 5.1 How to Use LAN EzLogger Pro ................. 5.2 EzLogger Pro Configuration ..................
  • Page 3 Table of Contents Chapter VII : Technical Specifications ............31 Chapter VIII : Certificationand Warranty ............32 8.1 Certification Mark ....................8.2 Warranty Certificate ....................8.3 Warranty Conditions ....................8.4 Disclaimer .........................

  • Page 4: Chapter I: Safety Precautions

    1. Prevent children from approaching EzLogger Pro. 2. Do not open the upper cover, unauthorized touching or replacement of components may cause personal injury and damage to EzLogger Pro, in this case, GoodWe will not be liable for such injury or damage or quality warranty.

  • Page 5: Chapter Ii: Product Introduction

    2.1 Product Introduction Introduce the main functions of EzLogger Pro. EzLogger Pro is a dedicated device for the photovoltaic power generation system monitoring and management platform, which achieves interface aggregation, data acquisition, data storage, centralized monitoring, centralized maintenance and other functions for the inverters, environmental monitor, watthour meter and other devices in the photovoltaic power generation system.
  • Page 6 2.2 Appearance Description Front of the box L=190mm Figure 2.2-2 Front View of EzLogger Pro Box Side of the box Figure 2.2-3 Side View of EzLogger Pro Box Port Port Description Reserved Port Sound alarm Buzzer sound hole Micro SD...
  • Page 7 2.2 Appearance Description Back of the box Figure 2.2-4 Back View of EzLogger Pro Box 1. Wall mounting hole 2. Rail clip 3. Cooling vents Top surface of the box Figure 2.2-5 Top View of EzLogger Pro Box 1. Reserved Slot...

  • Page 8: Description Of Led Indicators

    2.3 Description of LED Indicators Bottom surface of the box Figure 2.2-6 Bottom View of EzLogger Pro Box Port Port Description POWER Adapter 12VDC input Ethernet port DRED or RCR function port Function reserved COM1 RS485 communication port 1 for inverter...
  • Page 9 3s Off alternately) parameter setting is not set Blue light Off No inverter data acquired by EzLogger Pro Number of inverters actually acquired by EzLogger Pro is equal to that to Blue light On the parameter setting Blue light flashes (1s...

  • Page 10: Chapter Iii: Equipment Installation

    3.1 Packaging Information Introduce the packaged accessories of EzLogger Pro. After opening the EzLogger Pro package, please check whether the accessories are complete and there is any apparent damage. If there is any damage or certain items are missing, please contact your dealer.

  • Page 11: Equipment Installation

    3.2.1 Choose the installation location The following points shall be considered when you select the installation location: 1. The ingress protection rating of EzLogger Pro is IP20, so it has no waterproof performance and is for indoor use only. 2. The installation method and location shall be suitable for the weight and size of EzLogger Pro.
  • Page 12 8mm, and the hole depth is 40mm. =8mm D=40mm Figure 3.2.2-2 Schematic Diagram of Rail Mounting 2. Install the guide rail on the wall. 3. Install EzLogger Pro on the guide rail. Figure 3.2.2-3 Schematic Diagram of Installation of Ezlogger Pro onto Guide Rail...

  • Page 13: Chapter Iv: Electrical Connection

    Introduce the ports of EzLogger Pro for connection with the inverters and their functions. The schematic diagram of the ports on the bottom surface of EzLogger Pro is as follows: Figure 4.1-1 Schematic Diagram of Ports on the Bottom Surface of Ezlogger Pro...

  • Page 14: Connection To The Inverter

    4.2 Connection to the Inverter 1. Below is the diagram of EzLogger Pro DI ports, where REF1 and REF2 occupy two ports respectively. REF1 REF2 Figure 4.1-2 Schematic Diagram of Ezlogger Pro DI Ports EzLogger Pro DI ports are compatible with RCR and DRED functions, and the ports for...
  • Page 15 2. First strip off the insulating layer at both ends of the communication cable. 3. Then connect one core of the communication cable with terminal A of EzLogger Pro COM port, and the other core with terminal B of EzLogger Pro COM port.

  • Page 16: Connection To The Environmental Monitor And Meter

    4.3 Connection to the Environmental Monitor and Meter Introduce how EzLogger Pro is connected to the environmental monitor and meter. When EzLogger Pro is connected to the environment monitor , meter and other devices, COM4 port shall be used. Schematic diagram of COM4 port is as follows: COM4 Figure 4.3-1 Schematic Diagram of EzLogger Pro COM4 Port...

  • Page 17: Connection To The Computer

    Please make sure that the RS485 + of the environmental monitor and meter is connected to COM4 “A” of EzLogger Pro, and the RS485 - of the environmental monitor and meter is connected to COM4 “B” of EzLogger Pro. Environmental monitor , meter and other devices can only be connected to COM4.
  • Page 18 1. Select a cable of appropriate length, and connect one end of the cable with the ripple control receiver. 2. Connect the other end of the cable with the corresponding DI port of EzLogger Pro, and refer to Section 4.2.1...

  • Page 19: Connection To Dred

    1. Select a cable of appropriate length, and connect one end of the cable with DRED. 2. Connect the other end of the cable with the DI port of EzLogger Pro; note the definition of the port, and refer to Section 4.2.1 Inverter RS485 communication connection method for detailed connection.

  • Page 20: Chapter V: Lan Ezlogger Pro Data Upload And Function Configuration

    EzLogger Pro can be connected to the Internet in a plug-and-play way simply through direct connection of the NET port of EzLogger Pro to the LAN port of the router and the enabling of the dynamic IP (DHCP) function of the router. The collected Data will be automatically uploaded.

  • Page 21: Ezlogger Pro Configuration

    1. How to Assign a Dynamic IP Address to EzLogger Pro: If the user has a dynamic IP, EzLogger Pro can be connected to the Internet in a plug-and-play way simply through the connection of the NET port of EzLogger Pro to the LAN port of the router with Internet cable.
  • Page 22 2. Configuration Method for EzLogger Pro Static IP Address: If the user has a static IP, it is necessary to switch EzLogger Pro to the static IP mode. That is, press the Reload key for about 10 seconds to reset and restart EzLogger Pro, The LEDs on EzLogger Pro will blink one after another from right to left.
  • Page 23 5.2 EzLogger Pro Configuration (4) Pop up the local connection dialog box, right-click on “Local Connection” and then click on “Properties”. Figure 5.2-4 Modification of the Properties of Local Connections Pop up a dialog box as below: Figure 5.2-5 Modification of Internet Protocol 4 (TCP/IPv4)
  • Page 24 “Internet Protocol 4 (TCP/IPv4)”, then complete the setting for the dialog box in accordance with the following requirements. The defaulted IP address for EzLogger Pro is 192.168.1.200. In order to put your computer and EzLogger Pro under the same network segment, you should set the IP address and the default gateway in 192.168.1.
  • Page 25 Put the above data into LAN configuration, and then click the “Set” button to complete the set. Now IP address of EzLogger Pro has been modified as the configuration as required by the user, and physical connection between EzLogger Pro and ProMate can be disconnected after the configuration is completed.
  • Page 26 5.2 EzLogger Pro Configuration 5.2.2 Quantity Configuration for Inverter Communication Port Terminal configuration is used for setting EzLogger Pro ‘s COM1,COM2,COM3 ports which the quantity of inverters connecting,assume port 1(corresponding communication port COM1) connecting the quantity of inverters is 7,then check port 1,the quantity settings is 7,click on “Set” button to finish the configuration.
  • Page 27 5.2 EzLogger Pro Configuration 5.2.3 Time Setting Time setting will synchronize the time of EzLogger Pro and inverter and the time of synchronization server. Click on “Set Time” to pop up the following dialog box, as shown in the figure below. Then click on “OK”...
  • Page 28 5.2 EzLogger Pro Configuration 5.2.4 Field Debugging ProMate can also be applied to field installation and debugging. After installation is completed, click on “Refresh” to show whether the inverter is online or not. If the system prompts “off line”, please check whether the connection cable has any problem, and then timely solve the problems till the system shows that all the inverter are “on line”.
  • Page 29 Inverters power means: All of the inverters’ sum of generate electricity power value. Load power means: Load consumption power. When start using DRED function , if EzLogger Pro detects inverter had earth fault,then it will trigger sound-light alarm function:buzzer will ring for 1 minute,and RUN LED will be lighting for 1 minute.

  • Page 30: Program Upgrade

    U disk with 2.0 port, FAT32 format ), insert the USB flash disk in to the USB port of EzLogger Pro, cut off the electricity to EzLogger Pro and then repower it, so as to enable automatic update of the program.

  • Page 31: Chapter Vi : Website Monitoring

    Step 1: Open the browser, then visit https://www.semsportal.com/Home/Login, and you can enter GOODWE monitoring platform homepage. Click Languange-English to select language. Then log in using the account of the administrator or installer.

  • Page 32: View Power Station Information

    6.2 Check the PV Plant Step 3： Add an EzLogger Pro in the PV plant。Click Management > Plants, select the corresponding PV plant and click Device Management. Figure 6.1-2 Add the Device 6.2 Check the PV Plant Check the power generation status and equipment information via SEMS Portal after adding the equipment to the monitoring platform.
  • Page 33 6.2 Check the PV Plant Step 3：Check the detailed information of the plant. 図 6.1-3 Plant Information...
  • Page 34 Chapter VII : Technical Specifications Chapter VII : Technical Specifications Introduce the technical indicators of EzLogger Pro. Communication management Inverter communication 3 x RS485 Communication PC communication 10/100M Ethernet Number of 60 (The number of devices connected to RS485 managed devices...
  • Page 35 8.3 Warranty Conditions On the premise that the product is used according to GoodWe User Manual, if any product failure occurs within the warranty period due to quality problems, GoodWe provides the following three ways of warranty according to the actual circumstances: 1.
