Kramer KDS-USB2 Kit Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
KDS-USB2-EN and/or
1 Quick start guide
Step 2: Get to know your KDS-USB2
KDS-USB2-EN
# Feature
1 Power LED
2 Link LED
3 Host LED
4 Activity LED
5 Config Button
6 Mode Button
7 USB Host Port
8 Link RJ-45 Connector
KDS-USB2-DEC
# Feature
9 USB Ports
10 Power LED
11 Link LED
KDS-USB2 Quick Start
KDS-USB2 Kit/KDS-USB2-EN/KDS-USB2-DEC
Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/KDS-USB2
upgrades are available.
KDS-USB2-DEC
Function
Lights blue when power is supplied. Off when the host computer does not supply power.
Lights green when a USB link is established between the encoder and the decoder.
Flashes slowly when the unit attempts to establish a link. Flashes quickly when in pairing mode.
Off when a link is not established.
Lights green when KDS-USB2
Flashes when in a suspended state.
Lights yellow when activity between the decoder and encoder/s is detected.
Off when in suspended mode.
For factory use.
Use for pairing KDS-USB2-EN
Connect to the host computer.
Connect to the KDS-USB2-DEC.
Function
Connect up to 4 USB type A devices.
Lights blue when power is supplied. Off when the host computer does not supply power.
Lights green when a USB link is established between the encoder and the decoder.
Flashes slowly when the unit attempts to establish a link. Flashes quickly when in pairing mode.
Off when a link is not established.
KDS-USB2 for the first time.
to download the latest user manual and check if firmware
1 Power adapter and cord (for KDS-USB2-DEC)
1 USB2 cable A male to B male (for KDS-USB2-EN)
is properly enumerated on the host computer.
with the KDS-USB2-DEC
P/N: 2 9 0 0 - 3 0 1 3 9 1 QS
decoder/s.
Rev: 2
