American Dynamics RJ860AP Series Specifications

Actual product may vary from photo
FEATURES
•
Supports up to ten
SpeedDome, SpeedDome
Ultra and Optima domes
•
Meets Class 2 LPS power
requirements
•
120 VAC or 230 VAC
input versions available
•
Diagnostic LEDs
mounted on PC board
•
Front cover can be
secured with a captive
screw
•
Surge protection
•
Hardware or line cord
power connection
RJ860AP Series
TEN POSITION J-BOX (RS-422)
The SpeedDome ® Ultra/Optima ten-position
J-Boxes provide Class 2 LPS power and data
communications for up to ten SpeedDome
Series programmable domes. Each J-Box
receives data from the compatible controller
and feeds that data to the dome.
The units contain diagnostic LEDs for RS-422
communication. Surge protection circuitry
within the J-Box arrests unexpected voltage
surges on exterior power and data lines to
protect interior equipment. The J-Boxes can be
surface-mounted to concrete, wood, or sheet
rock with supplied hardware.
www.americandynamics.net
