- Page 1 CIS-CRS112-8P L2-L3 MANAGED NETWORK SWITCH PRODUCT MANUAL...
-
Page 2: Table Of Contents
CIS-CRS112-8P MANAGED L2-L3 NETWORK SWITCH PRODUCT MANUAL Table of Contents 1. Welcome to Custom Integration Solutions™ 2. Package Contents 3. Overview • Power • PoE Output • Ports • LED Indicators • Buttons • Input Power Requirements 4. Accessing the Web Interface •... - Page 3 CIS-CRS112-8P MANAGED L2-L3 NETWORK SWITCH PRODUCT MANUAL Table of Contents (continued) 7. VLANs • Purchase VLAN Configuration • VLAN Configuration • Adding Ports to the VLAN(s) 8. PoE Information and Settings • PoE-Out Modes • PoE-Out Limitations • Enable/Disable PoE on a Specific Port 9.
-
Page 4: Welcome To Custom Integration Solutions
1. Welcome to Custom Integration Solutions™ Thank you for purchasing CIS devices. Our solutions make it easy for integrators to deploy networks in home and business settings with minimal configuration. Our support team can provide assistance in setting up the equipment and answering your questions. -
Page 5: Ports
Reset button: Hold this button while the device is powered off, then apply power. Keep holding until the USR LED light starts flashing, (5 seconds) then release the button to reset to the default CIS configuration. You can use this procedure if you have forgotten the password to access the device, or simply wish to return the unit to its default configuration state. -
Page 6: Accessing The Web Interface
1. Connect your laptop to any remaining port on the front of the CIS Switch. Ensure your computer is set to DHCP mode. 2. Obtain the IP address of the CIS switch in the DHCP leases of your CIS router. Open a web browser and enter the IP address in the address bar. -
Page 7: Set The System Identity
CIS-CRS112-8P MANAGED L2-L3 NETWORK SWITCH PRODUCT MANUAL Set the System Identity The system identity is used to identify your device on the network. Set the switch to something that can uniquely identify it. The Identity setting can be found in the System tab in the left toolbar. -
Page 8: Changing The Default Password
PRODUCT MANUAL Changing the Default Password The default username is cis and the password is integration. After you log in for the first time, please create a new a password to increase the security of the device. Rebooting the Device CIS discourages rebooting your switches. -
Page 9: Ip Addressing
The IP address is the master interface for the switch. By default, the switch is set to DHCP and will acquire an IP address. The switch will support 172.16.1.0/24, 10.100.1.0/24, 192.168.1.0/24, and 192.168.0.0/24 networks by default. Should you require a different network address, please contact CIS Services for assistance. The DHCP Client tab The DHCP Client tab will present you with the IP address assigned to the switch from your router. -
Page 10: Setting A Static Ip Address
CIS-CRS112-8P MANAGED L2-L3 NETWORK SWITCH PRODUCT MANUAL Setting a Static IP Address To set a static IP, select the disabled interface. Prior to setting a static address, perform an IP scan on the LAN to confirm available addresses (see the tools section). In the address field, set the address you would like to use for the switch. Ping the switch to confirm the IP address responds. -
Page 11: View And Set Interfaces
CIS-CRS112-8P MANAGED L2-L3 NETWORK SWITCH PRODUCT MANUAL 6. View and Set Interfaces The Interfaces tab provides a glance at the activity on all ports. You can view the traffic sent and received, the status of PoE, PoE settings, PoE priority and current being drawn by PoE devices. -
Page 12: Loop Protect
CIS-CRS112-8P MANAGED L2-L3 NETWORK SWITCH PRODUCT MANUAL Loop Protect The Loop Protect feature can prevent Layer 2 loops by sending loop protect protocol packets and disabling interfaces in the event they receive loop protect packets originating from themselves. The feature works by checking the source MAC address of received loop protect packet against MAC addresses of loop protect enabled interfaces. -
Page 13: Vlans
PRODUCT MANUAL 7. VLANs Purchase VLAN configuration For a complete VLAN model, the router, access points and switching all require configuration. VLANs and additional networks are available on the CIS Store. Additional components are required for VLANs to function. https://www.custom-integration-solutions.com/store/cis-vlan-interface/ https://www.custom-integration-solutions.com/store/cis-additional-network/ VLAN Configuration If you have purchased the VLAN service, you can edit the settings in the VLAN tab of the Interfaces section. -
Page 14: Adding Ports To The Vlan(S)
CIS-CRS112-8P MANAGED L2-L3 NETWORK SWITCH PRODUCT MANUAL Adding Ports to the VLAN(s) Once an additional network has been created, a bridge interface will be selectable on the Bridge Ports tab. Select the ethernet port to link to your VLAN. Select the bridge from the drop down menu. This port will now access the IP address and configuration broadcast by the rout-... -
Page 15: Poe Information And Settings
PoE supplying devices also have a total current limitation which can't be exceeded, even if individual port limit allows it. All CIS equipment uses the same PoE-Out pin polarity Mode B 4,5 (+) and 7,8 (-), however other vendors can use opposite o r... -
Page 16: Tools And Other Protocols
IP tab in the left toolbar. UPnP CIS devices support Universal Plug and Play architecture for transparent peer-to-peer network connectivity of network- enabled intelligent devices or appliances. UPnP allows a wide range of devices to seamlessly discover each other’s presence on the network and establish communications. -
Page 17: The Ip Scan Tool
CIS-CRS112-8P MANAGED L2-L3 NETWORK SWITCH PRODUCT MANUAL The IP Scan Tool The IP Scan tool can scan the network based on a network prefix or setting an interface to listen to. When using IP scan tool the user must choose what they would like to scan for: IPv4 range •... -
Page 18: Warranty Information
Custom Integration Solutions™ or a designated service center with prior notification and an assigned return authorization (RA) number. Contact Information Web: www.custom-integration-solutions.com Phone: Technical Support - (888) 976-3651 Email: activations@custom-integration-solutions.com The CIS-CRS112-8P is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EC.
