9. Confirm that the selected file is correct for the Controller you wish to program.
10. Programming is ready to commence, select the program button to continue.
11. The Operating System Code will now be written to the iMAC Controller and verified afterwards.
12. Once the process is complete, apply a power cycle to the controller, the controller will boot using the
newly installed firmware.
13. Verify the correct Operating System Firmware was installed by viewing the VERSION PAGE on the
Controller. The highlighted text shows the Operating System version string.
The version page can typically be viewed by:
NOTE
Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version

Figure 17: iTools Write Operating System Code

H / W D A L S V 2 . 0 J U L 9 8
F / W M O N 5 V 1 . 0 M A Y 9 7
S / W O . S . V 4 . 2 O C T 2 0
S L P C O D E V E R S I O N S T R

Figure 18: Operating System Firmware Version

1. Pressing the MENU keypad button on the controller
2. Then pressing the DOWN ARROW button until the Version
Page option is shown
3. Then press the function key: F2, F3, or F4 corresponding to the
Version Page option
