GASGUARD
Programmable Intrinsically Safe Controller
INSTALLATION, OPERATION & MAINTENANCE MANUAL
Revision 2
Issued: 04/10/2011
CRN: 7502
Ampcontrol User Manual Part No: 120875
Designed and Manufactured in Australia by Ampcontrol CSM Pty Limited.
