American Dynamics RABW4QUAD Installation And Setup Manual

Black & White Camera
Kit with Quad Splitter
Video Surveillance
System
Installation and Setup Guide
Cameras (4)
Monitor
RABW4QUAD
Qty Description
4 1/3" B/W Indoor Fixed Camera
4 3.5-8mm Variable Focal Lens
1 12" B/W Video Monitor
1 24hr Time lapse VCR
3 25' BNC-BNC Patch Cord
1 B/W Standard Quad Splitter
4 100' Composite Video and Power Cables
4 Transformers
4 Wall Mounts
4 Fixed Camera Install Kit
Contents
About this Guide ................................................ 1
Before You Begin............................................... 1
Installation Overview.......................................... 2
Preparing Cameras............................................ 3
Connecting Cables to the Quad Splitter ............ 3
Adjusting the Lenses ......................................... 4
Troubleshooting ................................................. 4
Video Does Not Appear on Monitor ............ 4
VCR Recording ........................................... 5
VCR Playback ............................................. 5
If you need assistance... ............................. 5
Declarations....................................................... 5
Regulatory Compliance............................... 5
Other Declarations ...................................... 5
© Sensormatic 2000
RABW4QUAD BLACK & WHITE CAMERA KIT WITH QUAD SPLITTER VIDEO SURVEILLANCE SYSTEM INSTALLATION AND SETUP GUIDE (8000-2752-03, REV. A)
Quad Splitter
VCR
1 OF 5

About this Guide

This installation and setup guide explains how to
connect the equipment included in your video
surveillance system. Each piece of equipment
includes its own operating instructions. These
instructions should be used for specific operating
information.

Before You Begin

1. Unpack and inspect each piece of
equipment.
If any equipment appears damaged, contact
your sales representative.
2. Locate the manuals for each piece of
equipment.
Manuals are included with each component.
Keep these manuals for future reference.
3. Read through the instructions before
installing any equipment.
Understanding the steps before starting helps
you identify any tools you might need.
4. Identify where each piece of equipment will
be installed.
Ensure that you have enough space for
installing the equipment.
5. Make that you have enough electrical
outlets to power the equipment.
To protect your equipment, you may want to
consider using a power strip with surge
protection.
6. Perform any pre-installation steps that are
needed.
Mark the locations for each component. Install
the lenses before mounting the cameras.
Route cables before installing other equipment.
7. Determine how the cables will be routed
between the cameras and the Quad Splitter.
Ensure that the cables do not cross sharp
objects or are subject to possible damage.
Consider using cable clamps or mounts to
keep the cables securely in place.
