Weider LEGACY SLANT BENCH User Manual page 8

3. Attach the Front Leg (2) to the Frame (1) with
two M10 x 63mm Bolts (16), two M10 Large
Washers (27), and two M10 Locknuts (19); do
not tighten the Locknuts yet.
4. Orient a Stabilizer (4) so that the widest sides
(A) of the 50mm Outer Caps (12) touch the floor.
Attach the Stabilizer (4) to the Rear Leg (3)
with two M10 x 65mm Carriage Bolts (18) and
two M10 Locknuts (19); do not tighten the
Locknuts yet.
5 Attach the Rear Leg (3) to the Frame (1) with
two M10 x 20mm Screws (25) and two M10
Washers (20).
See steps 2–4. Tighten the M10 Locknuts (19).
3
27
16
27
4
3
12
A
5
8
1
19
2
19
4
12
A
18
3
1
20
25
