6. Insert a Pad Tube (10) into the Front Leg (2).
Next, slide a Foam Pad (9) onto each end of the
Pad Tube. Then, press two Pad Caps (11) into
the Pad Tube.
Repeat this step with the other Pad Tube (not
shown), Foam Pads (9), and Pad Caps (11).
7. Attach the Pivot Bracket (6) to the Backrest
Frame (5) with two M10 x 70mm Bolts (26) and
two M10 Locknuts (19); do not tighten the
Locknuts yet.
6
11
9
11
7
19
9
10
2
9
9
9
11
5
6
26
11
