X1-Hybrid User Manual
3.0kW - 7.5kW
EN
Copyright Declaration
ADD:No.288 Shizhu Road, Tonglu Economic Development Zone,
Tonglu City, Zhejiang Province, China.
Tel:+0571-5626 0011
E-mail： info@solaxpower.com
614.00495.00
