INSTALLING YOUR MICROWAVE

Step 8: Option B - Mount the microwave

CAUTIONS:
• For easier installation and personal safety, we recommend that two people install this product because of the weight. We highly
recommend professional installation if any electrical or carpentry work is required.
• Do not grip or use the handle during installation.
• To keep the power cord tight while mounting the microwave oven, thread the power cord through the hole in the bottom of the top
cabinet.
1 If your cabinet is metal, insert the nylon grommet into the power cord hole to prevent cutting the cord.
2 Lift the microwave, tilt it forward, and hook the slots on the back bottom edge onto the four lower tabs of the
mounting plate. Rotate the front of the microwave up against the bottom of the cabinet.
Notes:
• We recommend using ller blocks if the front of the cabinet hangs below the cabinet's bottom shelf.
• If ller blocks are not used, damage may occur from over-tightening the screws.
• Be sure to keep the power cord tight.
• Do not pinch the cord, especially when mounting ush to the bottom of the cabinet.
3 To attach the microwave oven to the top cabinet, insert two self-aligning machine screws through the holes you drilled
in the bottom of the cabinet. Turn each screw at least two full turns (they will be fully tightened later).
30
Thread the power cord through the
cable hole in the top cabinet. Keep it
tight throughout steps 1-2.
Front of cabinet
Bottom of cabinet
Filler block (optional)
Equivalent to depth of cabinet recess
Self-aligning machine screw
Top of microwave
