- Page 1 HANSEN QUEEN BED MBHANQBAWA...
- Page 3 1 Bed Head 2 Side Rail(x2) 1 Foot Rail 4 Center Leg 3 Middle Rail 5 Slat(x4) 6 Leg(x4) A Bolt(x16) B Washer(x16) C Bolt Large D Hexa Nut E Spanner Big F Spanner G Allen Key...
- Page 4 ② ① Step 1: Align the side rails with the Bed Head & Foot rails shown in the diagram below. Unscrew the hex head bolts and remove them from the brackets.
- Page 5 Step 2: Fit the end rails and side rails together so that the bolt holes overlap. Make sure the labels on each side match as shown in the diagram below. Fit the hex head bolt removed in Step 1 into the hole and tighten it with the spanner E.
- Page 6 ⑥ Step 3: Align a leg with the bottom of the frame formed in Step 2. Make sure the label on the leg matches the label on the side as shown in the diagram below. Fit a washer B to a bolt A and then insert the bolt into a hole. Tighten the bolt with the Allen key G.
- Page 7 ④ ③ Step 4: Fit the middle legs to the middle rail and make sure the holes overlap. Insert the long bolt C into the hole and make sure it protrudes from the other side. Attach the hex nut D to the bolt and tighten it with the spanner F.
- Page 8 Step 5: Place the structure formed in Step 4 upon the slots of the end rails. Once placed securely, middle legs should be 2-3mm o the ground.
- Page 9 ⑤ Step 6: Place the slat sets on the bed frame. Make sure the Flat End sits close to the bed ends while Protruding End sits in the centre.
- Page 10 Step 7: Place the bed in its desired location and enjoy your new Bed !
- Page 11 NOTES...
-
Page 12: Need More Information
NEED MORE INFORMATION? We hope t hat t his user guide has given you the assistance needed for a simple set-up. For any additional assistance you may require, head online t o help.mattblatt.com.au MJ\TT BLATT...
