Sealey GSA67.V2 Instructions

thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to Wear eye
instructions protection
1. Safety
follow all workshop Health & safety rules, regulations, and conditions when using tool.
9
Warning! disconnect from air supply before changing grinding bit or servicing.
‰
maintain die grinder in good condition and replace any damaged or worn parts. use genuine parts only. unauthorised parts may be
9
dangerous and will invalidate the warranty.
Warning! check correct air pressure is maintained and not exceeded. We recommend 90psi.
‰
Keep air hose away from heat, oil and sharp edges. check air hose for wear before each use and ensure that all connections are secure.
9
Warning! Before each use check grinding bit is secure, and the bit is not worn or damaged. if damaged, replace immediately.
‰
ensure replacement grinding bits are not damaged (cracks, deformations or splinters etc).
9
Always use the correct grinding bit suitable for the material being ground. ensure the maximum speed specification of the bit is higher than
9
that indicated on the machine data plate.
Warning! Always wear approved eye or face protection when operating the die grinder.
‰
use breathing protection in accordance with cosHH regulations if fumes or dust pose a hazard.
9
Wear ear defenders and safety gloves.
9
Keep hands and body clear of the work piece when operating the die grinder.
9
maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
9
secure unstable work piece with a clamp, vice or other adequate holding device.
9
Keep children and non essential persons away from the working area.
9
Avoid subjecting grinding bit to excessive strain, always ease grinding bit against work piece (a harsh impact may break the bit). maintain a
9
controlled adequate progression.
dO nOt get the die grinder wet or use in damp or wet locations.
8
dO nOt hold the workpiece by hand. use clamps or a vice to secure the work piece.
8
dO nOt use the die grinder for a task it is not designed to perform.
8
dO nOt use die grinder if damaged or faulty. contact your local service agent.
8
dO nOt use die grinder unless you have been instructed in its use by a qualified person.
8
dO nOt carry the die grinder by the air hose, or pull the hose from the air supply.
8
dO nOt direct air from the air hose at yourself or others.
8
dO nOt grind any materials containing asbestos.
8
dO nOt turn the die grinder on whilst the grinding bit is in contact with the work piece.
8
dO nOt use die grinder where there are flammable liquids, solids or gases such as paint solvents, including waste wiping or cleaning rags
8
etc as generated sparks may be dangerous.
dO nOt touch the work piece close to the ground surface as it will be very hot. Allow to cool. the work piece may also be very sharp.
8
dO nOt operate die grinder if you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
When not in use disconnect from air supply and store in a safe, dry, childproof location.
8
WArninG! danger of fire/explosion hazard
‰
WArninG! the grinding process can produce streams of sparks which are a potential source of ignition especially when grinding metal.
‰
do not use the grinder where there are flammable liquids, solids or gases.
8
do not allow grinder sparks to make contact with clothing or other fabric such as cleaning rags. fabrics contaminated with flammable
8
materials such as petrol, oil, paint and solvents are a particular fire hazard.
to reduce the risk of clothing catching fire the operator should wear clothing treated with a fire retardant.
9
WArninG! – risk of Hand Arm Vibration injury.
‰
this tool may cause Hand arm Vibration Syndrome if its use is not managed adequately.
this tool is subject to the vibration testing section of the machinery directive 2006/42/ec.
this tool is to be operated in accordance with these instructions.
measured vibration emission value (a): ................. 1.1 m/s²
uncertainty value (k): ........................................... 0.55 m/s²
Please note that the application of the tool to a sole specialist task may produce a different average vibration emission. We recommend
that a specific evaluation of the vibration emission is conducted prior to commencing with a specialist task.
© Jack sealey limited
instructions for
air die grinder kit 15pc
model no:
Wear protective Wear ear
gloves protection
Original Language Version
gSa67.V2
Wear a mask
GsA67.V2 | issue 1 16/01/17
