Amana ADB1000AW Dimension Manual

PRODUCT MODEL NUMBERS
ADB1000AW
Electrical: 120-volt, 60 Hz, AC-only, 15 or
20 amp. electrical supply. Use copper wire only. A
time-delay fuse or circuit breaker and separate
circuit is recommended.
Water: A hot water line with 20-120 psi
(138-862 kPa) water pressure. Water temperature
must be 120°F (49°C) at dishwasher. Use 3/8" O.D.
copper tubing with compression fitting (
minimum plastic tubing is optional but not
recommended). Use a 90° elbow with
external pipe threads on one end to connect to
water inlet valve. Do not solder within 6" (15.2 cm)
from water inlet valve.
Drain: Use the new drain hose supplied with your
dishwasher. If this is not suitable, use a new drain
hose with a maximum length of 12 feet (3.7 m) that
meets all current AHAM/IAPMO test standards, is
resistant to heat and detergent, and fits the drain
connector of the dishwasher. Must have a high
drain loop 20" (50.8 cm) above the subfloor or floor.
Connect drain hose to waste tee or disposer inlet
above drain trap in house plumbing and 20"
(50.8 cm) minimum above the floor. An air gap
must be used if the drain hose is connected to
house plumbing lower than 20" (50.8 cm) above
subfloor or floor. Use 1 ⁄ " minimum I.D. drain line
2
fittings.
Corner location: Requires a 2" (5.1 cm)
minimum clearance between the side of the
dishwasher door and wall or cabinet.
A side panel kit is available from your dealer for
installing your dishwasher at end of cabinet.
Grommet is required for electrical cable or power
supply cord hole cut in a metal cabinet.
Do not install dishwasher over carpeted floor.
CUSTOM FRONT PANEL DIMENSIONS (Framed)
These panels fit only models with frames around the door and access panels.
7 ⁄ "
32
(5.6 mm)
door panel
3 ⁄ "
8
(side view)
(9.5 mm)
18 21 ⁄ "
3 2
1" (47.4 cm)
(25.4 mm)
7 ⁄ "
32
(5.6 mm)
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Undercounter Dishwasher
OVERALL DIMENSIONS
1 ⁄ "
2
3 ⁄ " N.P.T.
8
CABINET OPENING DIMENSIONS
door panel (front view)
NOTE: Access panel is wider than door panel.
access panel
(front view)
22 31 ⁄ "
3 2
(58.3 cm)
24" (61 cm)
33 7 ⁄ "
8
(86 cm) min.
*
to front of
door frame
20
(52.7 cm)
24" (61 cm)
* Measured from the lowest point on the
underside of countertop. May be reduced
to 33 7 ⁄ " (86 cm) by removing wheels from
8
dishwasher.
** Minimum, measured from narrowest point
of opening.
6"(15.2 cm)
4" (10.2 cm)
4"
(10.2 cm)
2 1 ⁄ "
2
(6.4 cm)
5" (12.7 cm)
2"
(5.1 cm)
Water line entering through the
left side of opening in shaded
areas makes connection easier.
Minimum 1 ⁄ " (12,7 mm) hole.
2
23 5 ⁄ " (59.2 cm)
1 6
All edges routed to 7 ⁄ " (5.6 mm) thickness.
3 2
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
*
3 ⁄ "
4
**
24" (61 cm)
6"(15.2 cm)
(10.2 cm)
10"
(25.4 cm)
(6.4 cm)
2"
5" (12.7 cm)
(5.1 cm)
Drain hose and power supply line entering through the right
side of opening in shaded areas makes connection easier.
Drain hose size: 1 1 ⁄ " (3.8 cm)
2
Power supply line hole-direct wired:
Power supply line hole-with plug: 1
Cut door panel to clear access panel when
door is in open position
side view
door opened
top view
access panel frame
23 7 ⁄ " (60.6 cm)
8
*
34" (86.4 cm) min.
4"
2 1 ⁄ "
2
3 ⁄ " (1.9 cm)
4
1 ⁄ " (3.8 cm)
2
.
door closed
door pivot
access panel
7 ⁄ " (5.6 mm) thick
3 2
1 ⁄ "
4
(6.4 mm) min.
Ref. 8535436-D-AM
07/06/09
