* When power supply unit is loaded on M9 fusion splicer.
* When power supply unit is detached from M9 fusion splicer.
During charging, the battery indicators will blink.
When battery charge completed, all of the indicators will be on steadily.
Note: 1. Before fusion splicing, please check if the remaining battery capacity is
over 20% to prevent battery capacity damage. When fusion splicing or heating
is needed but battery level is lower than 20%, please detach the battery but you
can use power adapter to support operation. 2. The temperature of battery will
increase during charging. So please do not charge for the adapter together with
battery or charge when fusion splicer is still in the carrying case.
There are 2 ways for viewing battery level.
① If the battery is connected to the slicer, then battery level will be displayed on the
upper right side of the screen.
② Battery level is indicated by battery LED indicator. You can press "PUSH" to
view the battery level. As shown below:
Loaded
Detached
BATTERY
INDICATOR
User's Manual
INNO Instrument, Inc.
Charging
Battery Status
PAGE
11
