HP ProDesk 600 G6 Product End-Of-Life Disassembly Instructions

HP ProDesk 600 G6 Product End-Of-Life Disassembly Instructions

Microtower pc

Advertisement

Quick Links

Product End-of-Life Disassembly Instructions
Product Category: Personal Computers
Marketing Name / Model
[List multiple models if applicable.]
HP ProDesk 600 G6 Microtower PC
HP ProDesk 600 G6 PCI Microtower PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HPI products to remove components and materials requiring selective treatment, as defined by EU
directive 2012/19/EC, Waste Electrical and Electronic Equipment (WEEE).
NOTE: Recyclers should sort plastic materials into resin streams for recycling based on the ISO 11469 plastic marking
code on the plastic part. For any questions on plastic marking, please contact
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries, excluding Li-Ion batteries.
Li-Ion batteries. Include all Li-Ion batteries if more
than one is provided with the product (such as a
detachable notebook keyboard battery, RTC coin
cell, etc.)
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
EL-MF877-00
Template Revision C
Last revalidation date 09-May-2018
Notes
With a surface greater than 10 sq cm
All types including standard alkaline, coin or button
style batteries
Battery(ies) are attached to the product by (check all
that apply with an "x" inside the "[ ]"):
[
[X] snaps
[
[
NOTE: Add detailed removal procedures including
required tools in the sections 3.1 and 3.2.
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Includes background illuminated displays with gas
discharge lamps
Lite-On 550W EPA92 PSU
HPI instructions for this template are available at
HP's Sustainability
] screws
] adhesive
] other. Explain
Power Cord
EL-MF877-01
Contact.
Quantity
of items
included
in product
2
1
1
1
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ProDesk 600 G6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HP ProDesk 600 G6

  • Page 1 [List multiple models if applicable.] HP ProDesk 600 G6 Microtower PC HP ProDesk 600 G6 PCI Microtower PC Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of HPI products to remove components and materials requiring selective treatment, as defined by EU directive 2012/19/EC, Waste Electrical and Electronic Equipment (WEEE).
  • Page 2 Quantity of items Item Description Notes included in product weighing > 25 grams (not including PCBs or PCAs already listed as a separate item above) Components and parts containing toner and ink, Include the cartridges, print heads, tubes, vent including liquids, semi-liquids (gel/paste) and toner chambers, and service stations.
  • Page 3 24. Remove the CPU from the board. 25. Remove the battery from the system board. 26. Remove Graphic card from MB. 27. Remove M.2 WLAN Card. 28. Remove front and rear Antenna cable. 29. Remove speaker from Chassis. 30. Remove the Card Reader from the Chassis. 31.
  • Page 4 Step5 Remove front bezel from chassis Step6 Remove the screw of strengthen beam Step7 Remove the strengthen beam from chassis Step 8 Remove the ODD cage EL-MF877-00 Page 4 Template Revision C Last revalidation date 09-May-2018 HPI instructions for this template are available at EL-MF877-01...
  • Page 5 Step 9 Disconnect HDD power cable and HDD SATA Step10 Use T-15 screwdriver to loose the screws of HDD cage cable from HDD Step11 Remove HDD from Chassis Step12 Remove HDD from HDD cage Step13 Disconnect all SATA data cables from MB Step14 Disconnect P3 cable from MB EL-MF877-00 Page 5...
  • Page 6 Step15 Disconnect CPU/ODD Power cables from MB Step16 Disconnect system fan cable from MB Step17 Use PH1 screwdriver to remove system fan from Step18 Disconnect cooler fan cable from MB chassis EL-MF877-00 Page 6 Template Revision C Last revalidation date 09-May-2018 HPI instructions for this template are available at EL-MF877-01...
  • Page 7 Step19 Use T-15 screwdriver to loose the screws and Step20 Use PH1 screwdriver to loose the screws and remove remove cooler the fan Step21 Separate the fan from cooler Step22 Remove memory from MB EL-MF877-00 Page 7 Template Revision C Last revalidation date 09-May-2018 HPI instructions for this template are available at EL-MF877-01...
  • Page 8 Step23 Rotate the handle and open it up Step24 Remove the CPU from the board Step25 Remove the battery from the system board Step26 Remove Graphic card from MB Step27 Remove M.2 WLAN Card Step28 Remove front and rear Antenna cable EL-MF877-00 Page 8 Template Revision C...
  • Page 9 Step29 Remove speaker from Chassis Step30 Remove the Card Reader from the Chassis Step31 Use T-15 screwdriver remove the PSU screws on Step32 Disconnect the PSU cable from the MB the Chassis EL-MF877-00 Page 9 Template Revision C Last revalidation date 09-May-2018 HPI instructions for this template are available at EL-MF877-01...
  • Page 10 Step33 Use T-15 screwdriver to loose the screws of MB Step34 Press the PSU latch on chassis from board Step35 Remove the PSU from chassis Step36 Remove MB from chassis Step37 Use PH1 screwdriver to remove screw for the Step38 Remove PSU cover EL-MF877-00 Page 10 Template Revision C...
  • Page 11 Step39 Use PH1 screwdriver to remove FG screw Step40 Disconnect fan connector and inlet connector Step41 Loose screws and remove PCA from case Step42 Use PH1 screwdriver to remove AC inlet & Fan screw Step43 Heat the solder of the Electrolytic Capacitors of greater than 2.5cm in diameter or height and Remove it EL-MF877-00 Page 11...
