INSTALLATION

1
Feed power cable up through hole in fixture (if needed),
and plug the barrel connector into the receptacle on the
bottom of CX Flex, and plug the provided power supply
into the nearest outlet. Use an outlet installed near the
equipment that is easily accessible.
3
Clean the desired surface with an alcohol pad allow it to
completely dry. Peel the red film from the VHB adhesive.
www.mtigs.com | T:800.426.6844
CX FLEX™ 4A PRODUCT MANUAL
2
Route the power cord out of the CX Flex using the
provided channels (marked in blue). The cable may exit
down through a hole in the fixture or out from any side.
4
Press down on the base plate for 20 seconds for full VHB
contact. Allow 24 hours for full VHB adhesion.
