STEP 1. (See Figure 1) Install both wheels.
● Remove shipping brackets from the wheel hubs.
● Install both wheels. Valve stems towards the
outside.
● Use four lug nuts per tire. Torque to 75 foot/lbs
(101 newton meters).
STEP 2. (See Figure 1) Install the tongue.
● Clamp the tongue to the front of the Blower frame.
● Use four bolts with washers, secure with nylock
nuts.
STEP 3. (See Figure 1) Install (or adjust) the hitch.
● Use two bolts and nylock nuts to attach the hitch
to the tongue (may have been pre-installed at the
factory).
NOZZLE AND
V-BELT PULLEY
85650RevA
STEP 4. (See Figure 2) Install the nozzle.
NOZZLE V-BAND
NOZZLE
FIGURE 2
SETUP AND INSTALLATION
● Adjust the height of the hitch so that when the
blower is hitched to the tow vehicle, the tongue is
at a slight downward angle. TWO BOLTS MUST
ALWAYS BE USED - DO NOT USE WITH JUST
ONE BOLT HOLDING THE HITCH.
● The nozzle should be 6-1/2" to 7-1/2" inches
(165 mm to 190 mm) above the ground when it is
pointed straight down.
● Clamp the black plastic nozzle to the nozzle and
V-Belt pulley using the nozzle V-band clamp.
● V-band must clamp both the plastic nozzle and the
nozzle pulley. Clamp must not touch the V-Belt.
● Do not over tighten the clamp, tighten only tight
enough to keep the plastic nozzle from slipping on
the pulley.
CLAMP
AS85650-05RevA
