DESCRIPTION

The Torrent Tow Behind Blower is Turfco
Product Number 85650.

INTENDED USE AND FUNCTION

The Blower is a towed debris blower intended to be
used on turf at sports turf fields and on golf courses.
The Blower is NOT intended to be used for any
purpose other than blowing debris from the turf. Use of
the Blower is intended at a properly prepared worksite
where deficiencies have been corrected to avoid
injury to bystanders and/or damage to the machine or
surrounding property. The Blower is not designed for
or intended to accept riders.
LOCATION AND DESCRIPTION OF THE BLOWER
MAJOR COMPONENTS (See Figure 6, 7 and 8)
See Figure 6, 7 and 8 for the location of the major
components of the Blower. Do not modify the Blower in
any manner. Do not operate the Blower with damaged
or inoperable components.
ENGINE
TONGUE
AND HITCH
12
Description
BATTERY BOX
FIGURE 6
Tongue and Hitch: The hitch is adjustable to
accommodate different hitch height on tow vehicles.
Adjustment should always keep the tongue at a
slight downward angle to the ground.
Wheels and Tires: The tires are non highway rated.
Towing is limited to 20 mph (32 Km/h).
Fuel Tank: The fuel tank holds 6 gallons (22.7 liter).
Always have the cap on the tank during operation.
Use unleaded gasoline.
Engine: The blower is equipped with a 27 HP (20.13
kW) gasoline engine with electric start. The engine
powers the Blower blades. Engine speed can be
controlled by using the wireless remote or by using
the optional auxiliary control panel. The engine is
equipped with a 15 amp charging system to maintain
BLOWER
ASSEMBLY
WIRELESS
REMOTE
CONTROL
REMOTE
RECEIVER
WINDOW
IGNITION
SWITCH
OPTIONAL
AUXILIARY
CONTROL PANEL
