TURFCO Torrent Operators Manual & Parts Lists page 10

SETUP AND INSTALLATION
STEP 7. (See Figure 5) Test the wireless remote control. Ensure that factory
activation of the remote and the receiver are still active. NOTE: For safety
reasons, a "long push" of the remote buttons is needed to send a signal, expect
a slight time delay.
● Check the batteries in the remote by pushing the "ENGINE STOP" button. The
small red and green indicator lights on the remote should blink. If not, remove
the cover on the rear of the remote and check the batteries.
● If equipped with the optional Auxiliary Control, set the key switch on the control
panel to "Wireless" (key turned straight up and down).
● Turn ignition switch ON - DO NOT START ENGINE. Observe green indicator
lights in the receiver window. If no lights are green and the bottom light
"POWER" is not green, there is no power to the receiver. Check the 12 volt
battery in the battery box.
● Point the remote at receiver window on the control tower and push the "ENGINE
STOP" button. Observe flashing red (orange) lights in receiver window. Top
light "IN" should flash when the button is pushed.
● Point remote at receiver window on the control tower and push the
button. The nozzle should rotate. Also observe flashing indicator lights in
receiver window.
● Turn ignition switch OFF.
If indicator lights flashed and the nozzle rotated, the remote is in communication
with the receiver.
If no lights change to orange and the nozzle does not rotate, communication with
the receiver has been lost. Refer to the service section in this manual to reactivate
the remote to the receiver and restore communication.
10
or
85650RevA
