- Page 1 Axon Body 3 Dock Installation Manual Models AX1026 and AX1027 Document Revision: C June 2020...
- Page 2 Axon Body 3 Dock Installation Manual AXON, Axon, Axon Body 3, Axon Body 3 Dock, Axon Device Manager, and Axon Evidence are trademarks of Axon Enterprise, Inc., some of which are registered in the US and other countries. For more information, visit www.axon.com/legal.
-
Page 3: Table Of Contents
Axon Body 3 Dock Installation Manual Table of Contents Introduction to the Axon Body 3 Dock ..................... 4 Axon Body 3 Dock Types ........................... 4 Additional Materials ........................... 5 Axon Body 3 Dock Information ........................ 5 Network Considerations and Configuration ................... 7 Axon Body 3 Cameras and Network Infrastructure ................ -
Page 4: Introduction To The Axon Body 3 Dock
Axon Body 3 Dock Types There are two types of Axon Body 3 Docks – an 8-Bay Dock and a 1-Bay Dock. they are designed to accept eight and one, respectively, Axon Body 3 cameras. 8-Bay Dock (AX1026) 1-Bay Dock (AX1027) Axon Enterprise, Inc. -
Page 5: Additional Materials
Ethernet cable Axon Body 3 Dock Information Information about Axon Body 3 Docks and the devices connected to them can be viewed in your agency’s Axon Evidence.com account by going to the Device Profile page for the dock. Your dock must be registered to use the Device Profile page. - Page 6 Axon Body 3 Dock Installation Manual The image below is a snapshot of an Axon Body 3 Dock 1-Bay Device Profile page in Axon Evidence.com, showing the status of a docked camera. Axon Enterprise, Inc. Page 6 of 25...
-
Page 7: Network Considerations And Configuration
Axon Body 3 Dock to securely upload the content securely to your agency’s Axon Evidence.com instance. The Axon Body 3 camera is true mobile device and when docked each camera must obtain its own IP address to establish a direct encrypted communication channel to your agency’s Axon Evidence.com instance. -
Page 8: Network Requirements
To get the dock up and running, you may need some assistance from your IT department. Firewall Configuration The dock and Axon devices do not require any incoming data ports for regular operation. For proper operation, Axon Body 3 cameras require the following out- bound firewall ports: •... -
Page 9: Axon Body 3 Dock Installation
1-Bay Docks can be placed on a desktop or shelf as needed. If you do not have an Axon Evidence.com account, Axon recommends that you contact your Axon administrator and ask for an account invitation. When the email invitation arrives, accept the invitation and create an account. -
Page 10: Dock Registration
For 1-Bay Docks, check for power by placing an Axon Body 3 camera in the dock and looking for the charging icon on the camera display. Once a dock is installed, it can be used to register and charge Axon Body 3 cameras. Dock Registration... -
Page 11: Wall Mounting An Axon Dock
41 °F to 95 °F (5 °C to 35 °C). Note: The wall mount for the 8-Bay Axon Body 3 Dock is the same as the mount used for Axon Body 2 and Axon Flex 2 6-Bay Docks. If you already have this wall mount, you can reuse it with the 8-Bay Axon Body 3 Dock by removing the core and 6-Bay Dock modules and attaching the 8-Bay Axon Body 3 Dock. -
Page 12: Dimensions
Axon Body 3 Dock Installation Manual Dimensions The dimensions below show the mounting hole locations of the Wall Mount Bracket and the overall size of the assembly with the dock attached. The power supply is designed to go behind the unit on the horizontal shelf. -
Page 13: Step 3: Identify Dock Placement
Axon Body 3 Dock Installation Manual 3. Use the screws provided in the dock wall mount kit to attach the dock to the bracket. 4. As the screws come out the back of the bracket, attach the washers and add the wing nuts. -
Page 14: Step 5: Attach The Wall Mount Bracket To The Wall (Drywall Mount)
Axon Body 3 Dock Installation Manual 8. Install the screws into the stud until there is 1/8” (3.2 mm) of space between the bottom of the screw head and the wall. This will allow the bracket to be placed onto the screws and settle in the keyhole (the holes in the bracket are shaped like keyholes to make it easier to adjust the mount’s... - Page 15 Axon Body 3 Dock Installation Manual 4. You can secure the cable in position with the attached zip tie and the associated slots in the bracket. 5. Plug the power supply cable into a power strip or nearby AC outlet.
-
Page 16: Troubleshooting And Other Information
Axon Body 3 cameras. Axon Body 3 Dock only functions as an Ethernet adapter, an unmanaged network switch, and charger. As long as an Axon Body 3 Dock has power and a network connection, it should function correctly. Go to help.axon.com... -
Page 17: Warnings
(such as grain, dust, or metal powders); and any other area where you would normally be advised to turn off your vehicle engine. Axon Flex, Axon Flex 2, Axon Body, Axon Body 2, Axon Body 3, Axon Fleet, and Axon Fleet 2 cameras contain wireless transmission technology that transfers radio frequencies over the air as a form of energy transfer. - Page 18 Axon recommends that the user err on the side of caution and power off the camera before entering the explosive environment. An Axon camera should be treated the same as a cellular telephone would be treated in this situation.
- Page 19 1. Handling the components. Ensure proper connections between the Axon components (e.g., the Axon Body camera is correctly inserted into the Dock). Do not drop, crush, disassemble, deform, open, incinerate, or insert foreign objects into the Axon system components.
- Page 20 5. Avoiding hearing damage. Hearing damage, impairment, or loss may occur and may be permanent if an Axon Flex or Axon Flex 2 camera is mounted near your head and used at high volume. Set the volume to a safe and comfortable level. Be advised that you can adapt over time to a higher volume of sound that may sound normal but can be damaging to your hearing.
- Page 21 The battery in the Axon Fleet power unit is designed to be installed in the passenger compartment of a vehicle. Do not install the Axon Fleet power unit in the engine compartment, on the exterior of a vehicle, or in any location that will continually expose it to direct sunlight, water, other liquids, or corrosive substances.
- Page 22 CAUTION! MAINTENANCE Failure to properly maintain or use the Axon system may cause the system to malfunction or fail to function properly or optimally, including failure to capture data and corruption of loss of data. To reduce the risk of malfunction, including failure, corruption or loss of data: 1.
- Page 23 The Axon systems have been tested and found to comply with the limits for Class A (8-Bay Dock) and Class B (1-Bay Dock) digital devices, pursuant to part 15 of the FCC Rules. 8-Bay Dock is recommended for commercial and industrial installation, not intended for residential use.
- Page 24 Contact Axon Technical Support for help. • Axon systems comply with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) the device may not cause harmful interference, and (2) the device must accept any interference received, including interference that may cause undesired operation.
-
Page 25: Compliance Marks
Axon Body 3 Dock Installation Manual of the Council. A copy of the original Declaration of Conformity can be found at www.axon.com. Compliance Marks CAN ICES-3(A)/NMB-3(A) CAN ICES-3(B)/NMB-3(B) Axon Enterprise, Inc. Page 25 of 25...
