The Head Unit Button Operation For The Setup Or Search List - Alpine iXA-W404 Owner's Manual

4
Press /ENTER.
The Radio source is activated and the display changes to
the Radio main screen.
Display example for FM Radio main screen
Displays the source name, such as radio band, etc.,
that is selected.
Display time, missed call
Function Guide:
The function guide display varies depending on each
source.
The contents of the function guide change by touching
2 2
[P1/2]* , [P1/3]* , [P1/4]*
and many other operations can be performed.
1
* Displayed when the optional BLUETOOTH INTERFACE
(KCE-400BT) is used.
2
* Display may vary depending on the connected devices.
5
Repeat the procedure to select another source.
• If no operation is performed for 5 seconds, during mode switching or
Audio/Visual source selection, the screen will automatically switch to
the current mode or source.
• You can select source in the Audio/Visual mode only.
The head unit button operation for the
Setup or Search list
When the unit is doing the setup setting or searching, operation of
setting or search can also be done using the buttons on the unit besides
touching the keys on screen.
1
When a setting or search list is activated, a selection
mark will appear. Rotating the Double Action
encoder can move the selection mark to choose the
item.
Display example for iPod search screen
Selection mark
10
-EN
1 1
, signal strength , etc.
* *
2
or [ ] on the function guide,
2
Press /ENTER.
You will enter into detailed setting or selection of this item.
• If there are several operation keys in the selected item, key selection
mode appears. Refer to "Operating the keys of item" on page 10.
• Pressing to return to the previous screen.
3
Complete the setting or search by performing steps
1 and 2 repeatedly.
Operating the keys of item
If there are several keys in the selected item, the item will be highlighted
and selection mark will appear on the key.
Display example for Audio Adjustment screen
Selection mark
The selected item
1
Rotating the Double Action encoder can move
the selection mark to choose the key of the selected
item (e.g. select [ ]).
2
Press /ENTER.
This operation has the same efficiency as touching the
selected key on the screen (e.g. touch [ ]).
• If the selected [ ] or [ ] key is used to adjust the value (e.g. NAV.
Mix Level), pressing and holding
will change the value continuously. The operation has the same
efficiency as touching and holding [ ] or [ ] for at least 2 seconds.
/ENTER for at least 2 seconds
