Yardline BERKDALE 14' x 8' Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

16769
STOP!
STOP!
Call Us First!
DO NOT RETURN TO STORE.
For immediate help with assembly or product information
call our toll free number:
1-800-844-9273
or email:
customerservice@yardline.net
Our staff is ready to provide assistance
M-F 8:00 AM to 6:00 PM EST
Saturday 8:30 AM to 5:00 PM EST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BERKDALE 14' x 8' and is the answer not in the manual?

Questions and answers

Related Manuals for Yardline BERKDALE 14' x 8'

Summary of Contents for Yardline BERKDALE 14' x 8'

  • Page 1 DO NOT RETURN TO STORE. For immediate help with assembly or product information call our toll free number: 1-800-844-9273 or email: customerservice@yardline.net Our staff is ready to provide assistance M-F 8:00 AM to 6:00 PM EST Saturday 8:30 AM to 5:00 PM EST...
  • Page 2 (This page intentionally left blank.)
  • Page 3 Inventory all parts listed on pages 3 - 7. Contact our Customer Service Team if any parts are missing or damaged. • ADDITIONAL MATERIALS You will need additional materials to complete your shed. See page 8 for required and optional materials and quantities. - CUSTOMER SERVICE - 800-844-9273 Call: 1- email: customerservice@yardline.net...
  • Page 4 TOOLS Required Optional Phillips Tool Belt/ Utility Knife Screwdriver Nail Pouch Shingle Blades Drill / Driver Caulk Gun 1/8" Drill Bit Tin Snips 1/4" Drill Bit (for drip edge) 5/16" Drill Bit Paint Tools 1/2" Drill Bit Chalk Line #2 Philips Drive Bit Safety Glasses Hammer Nail Gun...
  • Page 5 PARTS IDENTIFICATION AND SIZES Part identification WOOD SIZE CONVERSION CHART letters are stamped on some parts. Nominal Board Size Actual Size 1" x 3"....3/4" x 2-1/2" (3,8 x 6,3 cm) 2" x 3"....1-1/2" x 2-1/2" (3,8 x 6,3 cm) 2" x 4"....1-1/2" x 3-1/2" (3,8 x 8,9 cm) Check these locations for 2"...
  • Page 6 WINDOW & DOOR TRIM 19/32 x 2-1/2 x 9" (1,5 x 6,3 x 22,8 cm) 19/32 x 2-1/2 x 26-5/8" (1,5 x 6,3 x 67,6 cm) 19/32 x 2-1/2 x 28-1/2" (1,5 x 6,3 x 72,3 cm) 19/32 x 2-1/2 x 30-1/8" (1,5 x 6,3 x 76,5 cm) 19/32 x 2-1/2 x 32-3/4"...
  • Page 7 WALL PANELS & DOORS NOTE: Panel parts are not stamped. 3/8 x 48 x 84" 3/8 x 48 x 33" 3/8 x 11-7/8 x 84" 3/8 x 48 x 84" 3/8 x 48 x 84" (1 x 121,9 x 213,4 cm) (1 x 121,9 x 83,8 cm) (1 x 30,2 x 213,4 cm) (1 x 121,9 x 213,4 cm)
  • Page 8 FLOOR PARTS Floor panels are 5/8" (1,6 cm) thick. NOTE: Panel parts are not stamped. 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) Look for TREATED Stamp 2 x 4 x 93" (5,1 x 10,2 x 236,2 cm) 2 x 4 x 96"...
  • Page 9 FASTENERS & HARDWARE FASTENER/HARDWARE BAG x140 1-1/2" (3,8 cm) x215 2" (5,1 cm) x120 3" (7,6 cm) 2" (5,0 cm) 3/4" (1,9 cm) Boxes 2" (5,1 cm) Boxes 3" (7,6 cm) DOOR HARDWARE/ WINDOWS Spring Bolt T-Handle Window - Large 1-1/2" (3,8 cm) 1"...
  • Page 10 ADDITIONAL MATERIALS FOUNDATION OR FLOOR MATERIALS • This shed does not include any leveling materials. • See the FLOOR LEVELING section on page 9 for recommended methods and suggested materials to properly level your floor, as this will vary depending on your specific site. •...
  • Page 11 OPTIONAL WOOD FRAME FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS (Typical for 8' x 14' Kit) Runners are generally 12" (30,5 cm) from ends of floor frame and under seams. Measurements to centers of 4x4's. 12" (30,5 cm) • 3" Screws angled into 4x4. • (2) at each point where frame 16" and 4x4 touch. 12" (40,6 cm) (30,5 cm) Fasteners for Frame to 4"x 4".
  • Page 12 CONCRETE FOUNDATION Your kit contains all materials to construct a wooden floor. If you choose to install your kit on a concrete slab refer to the diagram below. Treated Sill Plate Caulk between sill plate and concrete. 3-1/2" (8,9 cm) 4"...
  • Page 13 FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) Look for 2 x 4 x 93" (5,1 x 10,2 x 236,2 cm) TREATED Stamp 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) BEGIN Orient parts as shown on flat surface.
  • Page 14 LEVEL AND SQUARE FLOOR FRAME Before attaching floor decking, it is important to level and square the floor frame. A level and square floor frame is required to correctly construct your shed. BEGIN See page 9 for the preferred floor leveling method. Use level and check the frame is level before applying floor panels.
  • Page 15 FLOOR PANELS PARTS REQUIRED: x219 2" (5,1 cm) 5/8 x 48 x 96" (1,6 x 121,9 x 243,8 cm) Ensure your floor frame is square by installing one panel and squaring frame. Install floor panels with the rough side up (painted grid lines side). BEGIN Install floor panels with the 48" edge and corner flush to the floor frame. Secure panel with two 2" nails in the corners (Fig A).
  • Page 16 FLOOR PANELS PARTS REQUIRED: 2" (5,1 cm) 5/8" x 23-7/8" x 96" (1,6 x 60,6 x 243,8 cm) 5/8" x 48" x 96" (1,6 x 121,9 x 243,8 cm) Continue installing the rest of your floor panels. Use a chalk line or use pre-painted grid lines on panel for 2" nails 6" apart on edges, and 12"...
  • Page 17 IMPORTANT! Check the floor frame is level after installing floor panels. Re-level if needed. • The floor should be used as a stable work surface for wall construction. • Organize your assembly procedure during the build process HINT: to avoid over-handling of the walls. GABLE END BACK WALL WALL BACK WALL FRONT WALL GABLE WINDOW WALL...
  • Page 18 GABLE WINDOW WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 8-3/4" (5,1 x 10,2 x 22,2 cm) 2 x 4 x 22-1/2" (5,1 x 10,2 x 57,1 cm) 2 x 4 x 38-1/4" (5,1 x 10,2 x 97,1 cm) 2 x 4 x 80"...
  • Page 19 GABLE WINDOW WALL PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 48 x 84" BLOCK (121,9 x 213,4 cm) x1 LEFT Place left 48" x 84" panel onto wall frame flush to top with primed side up. Use GAA Gauge Block to maintain 3/4" along panel edge as shown. Secure panel with 2" nails 6" apart on edges and 12"...
  • Page 20 GABLE WINDOW WALL PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 48 x 84" BLOCK (121,9 x 213,4 cm) x1 RIGHT Place right 48" x 84" panel onto wall frame flush to top and left panel as shown. Secure panel with 2" nails 6" apart on edges and 12" apart inside panel. Flush 6"...
  • Page 21 BACK WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) HINT: BEGIN For easier nailing...
  • Page 22 BACK WALL PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 48 x 84" BLOCK (121,9 x 213,4 cm) Place 1st 48 x 84" panel onto wall frame flush to top of frame with primed side up as shown. Use the Gauge Block GAA to mark the 3/4" measurement on the wall stud. Secure panel with two 2"...
  • Page 23 BACK WALL PARTS REQUIRED: x164 2" (5,1 cm) 48 x 84" 11-7/8 x 84" (121,9 x 213,4 cm) (30,2 x 213,4 cm) Place 2nd 48" x 84" panel flush to top of frame as shown. Nail using 2" nails 6" apart on edges Flush Flush and 12"...
  • Page 24 GABLE END WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 80" (5 x 10,2 x 203,2 cm) 2 x 4 x 89" (5 x 10,2 x 226,1 cm) Temporary support Temporary support 19/32 x 2-1/2 x 9" 2 x 4 x 18-1/8" (1,5 x 6,3 x 22,8 cm) (5,1 x 10,2 x 46 cm) BEGIN...
  • Page 25 GABLE END WALL PARTS REQUIRED: 1-1/2" (3,8 cm) 2" (5,1 cm) 48 x 84" (121,9 x 213,4 cm) Place 48 x 84" panel with primed side up onto frame flush at top and with a 1-3/4" gap along right side. Maintain 1-3/4" measurement along edge.
  • Page 26 GABLE END WALL PARTS REQUIRED: 1-1/2" (3,8 cm) 2" (5,1 cm) 48 x 84" (121,9 x 213,4 cm) Place 2nd 48 x 84" panel flush to installed panel. 2" (5,1 cm) Secure using 2" nails 6" apart on edges. Nails Flush 1-1/2"...
  • Page 27 FRONT WALL (DOOR HEADER ASSEMBLY) PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 67" (5,1 x 10,2 x 170,1 cm) 3" (7,6 cm) 7/16 x 3-1/2 x 67" (1,1 x 10,2 x 170,1 cm) OSB 2 x 4 x 8" (5,1 x 10,2 x 20,3 cm) BEGIN Lay out parts as shown flush along all edges.
  • Page 28 FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 52" (5,1 x 10,2 x 132 cm) 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm) D O O R H E A D E R 2 x 4 x 80" (5,1 x 10,2 x 203,2 cm) 2 x 4 x 84"...
  • Page 29 FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 8-3/4" (5,1 x 10,2 x 22,2 cm) 2 x 4 x 22-1/2" (5,1 x 10,2 x 57,1 cm) Measure and mark to the dimension at each location. HINT: For easier nailing stand on frame.
  • Page 30 FRONT WALL PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 3/8 x 48 x 84" (1 x 121,9 x 213,4 cm) BEGIN Place 48" x 84" panel onto wall frame flush to top of frame as shown. Use the gauge block GAA to mark the 3/4"...
  • Page 31 FRONT WALL PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 3/8 x 48 x 84" BLOCK (1 x 121,9 x 213,4 cm) Place 48 x 84" panel onto wall frame flush to top of frame and installed panel as shown. Use the gauge block to mark the 3/4" measurement on the wall stud. Secure panel with 2"...
  • Page 32 FRONT WALL PARTS REQUIRED: 3" (7,6 cm) x102 2" (5,1 cm) 3/8 x 36 x 84" 3/8 x 36 x 84" (1 x 76,2 x 213,4 cm) (1 x 76,2 x 213,4 cm) Temporary Support 2 x 3 x 96" (5,1 x 10,2 x 243,8 cm) Place left and right 36"...
  • Page 33 BACK WALL PARTS REQUIRED 3" (7,6 cm) 2 x 3 x 63-5/16" (5,1 x 7,6 x 160,8 cm) 3" (7,6 cm) 2" (5,1 cm) You can install your window gable wall on either end of the shed. BEGIN BACK WALL Stand on floor.
  • Page 34 GABLE END WALL PARTS REQUIRED: 1-1/2" (3,8 cm) 3" (7,6 cm) 2" (5,1 cm) 3" (7,6 cm) 2" (5,1 cm) You can install your window gable wall on the left or right side of the shed. See page 35. Left Right BEGIN Choose your gable wall location (Solid Wall shown).
  • Page 35 FRONT WALL PARTS REQUIRED: 2" (5,1 cm) 3" (7,6 cm) 1-1/2" (3,8 cm) BEGIN Stand front wall on floor. Center front wall on the 168" (426,7 cm) floor dimension. Secure top and bottom of wall using one 2" screw into top and bottom plate (Fig A). BE SURE TOP OF WALL FRAMES ARE FLUSH.
  • Page 36 FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) Nail lower edge of front wall panels to floor frame using 2" nails 6" apart. Angle nail to hit floor frame (Fig. D). Secure front wall bottom plates to floor using 3" nails (Fig. D). 3"...
  • Page 37 GABLE WINDOW WALL PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) 2" (5,1 cm) 3" (7,6 cm) 1-1/2" (3,8 cm) BEGIN Remove temporary support XZA from back wall and floor frame. Set gable window wall on floor and secure using one 2" screw in each corner (Fig A, B). ENSURE TOP WALL FRAMES ARE FLUSH.
  • Page 38 GABLE WINDOW WALL PARTS REQUIRED: Nail lower edge of panels to floor using 2" nails 6" apart. Angle nail to hit floor frame (Fig. C). 2" (5,1 cm) Nails Angle nail to hit floor frame. 6" (15,2 cm) Fig. C 3" (7,6 cm) Screw Fig. F 6"...
  • Page 39 RAFTER ASSEMBLY PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 56-15/16" (2,5 x 10,26 x 144,6 cm) x168 2" (5,1 cm) 3/4" GAUGE BLOCK You will build 8 RAFTERS. (2) RAFTERS will have ONE gusset. (6) RAFTERS will have TWO gussets. BEGIN Make a jig so rafters will all have the same measurement using the shed floor and 3/4"...
  • Page 40 RAFTERS PARTS REQUIRED: 3" (7,6 cm) RAFTER ASSEMBLY RAFTER ASSEMBLY WITH 1 GUSSET WITH 2 GUSSETS BEGIN Mark top plates to measurements shown. Place TWO gusset rafters flush to inside of front and back wall panels (Fig. A, Fig. B). Secure rafters with two 3" screws at rafter end. Place the ONE gusset rafters flush to the outside of the gable wall panels and flush to outside top plate of front and back walls (Fig. C).
  • Page 41 GABLE UNITS PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 4 x 12-1/2" (5,1 x 10,2 x 31,8 cm) 2 x 4 x 18-1/8" (5,1 x 10,2 x 46,0 cm) BEGIN Orient parts on flat surface as shown. Place left front gable panel as shown and secure using 1-1/2" nails as shown. 1-3/4"...
  • Page 42 GABLE UNITS PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 4 x 23-7/8" (5,1 x 10,2 x 60,6 cm) Orient parts on flat surface as shown. Place left back gable panel as shown and secure using 1-1/2" nails as shown. 1-3/4" (4,4 cm) XWA (on flat) 1-1/2"...
  • Page 43 FRONT GABLE UNIT PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) Front Gable Unit NOTE: Install the gable unit with the window on the wall with the window. BEGIN Set front gable unit on top plate. Be sure gable unit is centered on wall before nailing. Nail gable panel into rafter and top plate with 2"...
  • Page 44 BACK GABLE UNIT PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) Back Gable Unit BEGIN Measure 2-9/16" down from top plate and mark at each side as shown. Set gable unit on top plate. Hold secure with one 2" nail on each as shown (Fig. A). BE SURE GABLE UNIT IS CENTERED ON WALL BEFORE NAILING.
  • Page 45 LOFT PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 96" (5,1 x 7,6 x 243,8 cm) 3" (7,6 cm) 3/4" 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) GAUGE BLOCK NOTE: Loft and shelves are designed to be installed on the Solid Gable Wall Side BEGIN Mark studs 3/4"...
  • Page 46 LOFT PARTS REQUIRED: 2" (5,1 cm) 7/16 x 26-5/8 x 88-3/4" (1,1 x 67,6 x 225,4 cm) Install loft panel with 2" nails FIT LOFT PANEL INTO 3/4" GAP ATTENTION: LOAD NOT TO EXEED 250 lbs (113,4 kg) EVENLY DISTRIBUTED 2" (5,1 cm) ACROSS LOFT Nails FINISH You have finished installing your loft.
  • Page 47 SHELVES PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 96" (5,1 x 7,6 x 243,8 cm) BEGIN Install both PT's using 3" screws as shown. 3" (7,6 cm) Screws 59-1/2" (150,21 cm) 41-1/2" (105,4 cm) Install both PT's using 3" screws as shown. 3"...
  • Page 48 SHELVES PARTS REQUIRED: 2" (5 cm) 7/16 x 10-1/2 x 88-3/4" (1,1 x 26,7 x 225,4 cm) Install shelves using 2" nails as shown. FINISH You have finished installing your shelves.
  • Page 49 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 7/16 x 15-1/16 x 48" 7/16 x 15-1/16 x 96" 7/16 x 15-1/16 x 23-7/8" (1,1 x 38,2 x 121,9 cm) (1,1 x 38,2 x 243,8 cm) (1,1 x 38,2 x 60,6 cm) Roof panels may cause serious injury until securely fastened.
  • Page 50 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 7/16 x 47-7/8 x 48" BLOCK (1,1 x 121,6 x 121,9 cm) Keep spacing between the center of the rafters at the upper edge of the panels. Secure panels with one 2" nail into each rafter (Fig. H). 24"...
  • Page 51 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 7/16 x 23-7/8 x 48" 7/16 x 48 x 96" (1,1 x 60,4 x 121,9 cm) (1,1 x 121,9 x 243,8 cm) Install 48" x 96" roof panel (Fig. K). use the 3/4" gauge block GAA to center the panel over the rafter (Fig. L). Secure panel with two 2"...
  • Page 52 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) Keep spacing between the center of the rafters at the upper edge of the panels. Secure panels with one 2" nail into each rafter (Fig. N). Use two nails at seams. From From 24-3/8" 24"...
  • Page 53 GABLE TRIM PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 3 x 63-5/16" (5,1 x 7,6 x 160,8 cm) LEFT 3/8 x 3-7/8 x 63-5/16" (1 x 9,8 x 160,8 cm) RIGHT 3/8 x 3-7/8 x 63-5/16" (1 x 9,8 x 160,8 cm) You will build two LEFT and two RIGHT gable trim units.
  • Page 54 GABLE TRIM PARTS REQUIRED: 3" (7,6 cm) RIGHT gable trim unit LEFT gable trim unit BEGIN Install LEFT and RIGHT gable trim units flush to peak and flush with top of roof sheathing (Fig. A, B). Secure with four 3" screws into end rafter and spaced evenly. Flush Fig. B Flush Fig. A 3"...
  • Page 55 GABLE TRIM PARTS REQUIRED: 2" (5,1 cm) LEFT 3/8 x 3-7/8 x 63-5/16" (1 x 9,8 x 160,8 cm) RIGHT 3/8 x 3-7/8 x 63-5/16" (1 x 9,8 x 160,8 cm) BEGIN Install LEFT and RIGHT fascia at peak and flush with gable trim unit (Fig. A, B, C). Secure with 2"...
  • Page 56 EAVE SIDE SOFFITS PARTS REQUIRED: 1-1/4" (2,5 cm) Screws) 2 x 6 x 56-1/2" (5,1 x 13,9 x 143,5 cm) BEGIN Install CRA's under roof panel, tight against wall panels and inner gable trim as shown (Fig. A, B). Use 1-1/4" screws through roof sheeting into CRA. Fig. A Tight against...
  • Page 57 EAVE SIDE FASCIA PARTS REQUIRED: 2" (5,1 cm) 3/8 x 3-7/8 x 78" (1 x 9,8 x 198,1 cm) 3" (7,6 cm) 3/8 x 3-7/8 x 96" (1 x 9,8 x 243,8 cm) BEGIN Install 78" and 96" fascia trim primed side out, flush to outer gable trim and top of roof sheathing. Secure using 2"...
  • Page 58 DOORS PARTS REQUIRED: 3" (7,6 cm) 2" (5 cm) x1 GAA 1 x 3 x 5" (2,5 x 7,6 x 12,7 cm) 1-1/4 x 2-1/2 x 69" (3,2 x 6,3 x 175,3 cm) Left Door Right Door BEGIN Orient parts as shown on flat surface. 3/8"...
  • Page 59 DOUBLE DOORS PARTS REQUIRED: 3" (7,6 cm) 1-1/4 x 2-1/2 x 69" (3,2 x 6,3 x 175,3 cm) Attach temporary support OO as a ledger board using two 3" screws (Fig. A) . Center doors in door opening (Fig. B) . Fig. A Flush against wall panels.
  • Page 60 DOOR TRIM PARTS REQUIRED: 3/4" (1,9 cm) 19/32 x 2-1/2 x 26-5/8" (1,5 x 6,3 x 67,6 cm) BEGIN Secure door trim from inside using 3/4" screws as shown (Fig. A). Attach AH with 3/4" screws from inside of doors (Fig. B). Reinforce the door trim using 3/4"...
  • Page 61 DOOR STIFFENERS PARTS REQUIRED: 2" (5,1 cm) 1-1/4 x 2-1/2 x 69" (3,2 x 6,3 x 175,3 cm) BEGIN Center OO vertically on the left door in the door opening flush with the edge of door (Fig. A). Secure using (6) 2" screws through outside trim into OO (Fig. B) Repeat Step 1 to install OO on right door.
  • Page 62 DOOR HARDWARE PARTS REQUIRED: 1-1/2" (3,8 cm) 1/4" (0,6 cm) 1/2" (1,3 cm) Drill Bits BEGIN Measure and mark location of hole on outside of right door as shown (Fig. A). Pre-drill pilot hole with 1/4" dril. Pre-drill through hole with 1/2" drill. Fig. A Keep drilled hole square to trim to avoid breaking...
  • Page 63 DOOR HARDWARE PARTS REQUIRED: 5/16" (0,8 cm) Drill Bit 1" (2,5 cm) BEGIN Place top bolt onto OO in open position with bolt ends 3/8" (1 cm) down from frame. Bolt is open when loop is contacting base (Fig A). Mark and pre-drill holes for screws. Install bolt with screws supplied and drill 5/16"...
  • Page 64 DOOR - DECORATIVE HINGES PARTS REQUIRED: 1" (2,5 cm) BEGIN Level decorative hinges in position as shown. Secure with 1" (2,5 cm) screws. 1" (2,5 cm) Screws Flush FINISH You have finished installing your decorative door hinges.
  • Page 65 CORNER TRIM PARTS REQUIRED: 2" (5,1 cm) 3/8 x 1-3/4 x 81-1/2" (1 x 4,4 x 207 cm) 3/8 x 1-3/4 x 83-3/8" (1 x 4,4 x 211,8 cm) ¸ BEGIN Attach one 83-3/8" trim board flush under soffit panel and against eave wall (Fig. A, B) using one 2"...
  • Page 66 COLLAR TIES PARTS REQUIRED: 2" (5,1 cm) 1 x 3 x 60" (1,6 x 6,3 x 152,4 cm) BEGIN Position and level collar ties GUA on 3rd and 5th rafters from gable end wall. Attach with 2" nails as shown. Flush Flush 2"...
  • Page 67 WINDOWS AND WINDOW TRIM PARTS REQUIRED: Window 2" (5,1 cm) BEGIN Seal window with high-quality exterior- grade caulk before installing (Fig. A). Attach window using four 2" (5,1 cm) screws as shown. Ensure window is level and centered. Fig. A Caulk behind frame near edge.
  • Page 68 WINDOW TRIM PARTS REQUIRED: 2" (5 cm) 19/32 x 2-1/2 x 28-1/2" (1,5 x 6,3 x 72,4 cm) 19/32 x 2-1/2 x 30" (1,5 x 6,3 x 76,2 cm) Place trim pieces ROR and AZ centered on window frame (Fig. A). Attach using 2" finish nails. CENTER OF WINDOW Fig. A...
  • Page 69 TRANSOM WINDOW PARTS REQUIRED: 3/4" (1,9 cm) Transom Window ¸ BEGIN Seal window behind flange edges with high-quality exterior-grade caulk before installing (Fig. A). Place transom window in gable opening. Ensure window is level and centered. Attach window using (6) 3/4" screws as shown (Fig. A). Fig. A Transom Window...
  • Page 70 TRANSOM WINDOW TRIM PARTS REQUIRED: 2" (5 cm) 19/32 x 2-1/2 x 32-3/4" (1,5 x 6,3 x 83,1 cm) BEGIN Center YR over transom window and secure using four 2" finish nails into framing as shown (Fig. A). Fig. A Center of 2" Finish Nails Window 4-1/2"...
  • Page 71 TRANSOM WINDOW TRIM PARTS REQUIRED: 2" (5 cm) 19/32 x 2-1/2 x 9" (1,5 x 6,3 x 22,8 cm) 19/32 x 2-1/2 x 32-3/4" (1,5 x 6,3 x 83,1 cm) Install (2) EY trim pieces using 2" finish nails into trim and panels as shown (Fig. B). Do not nail into window flange.
  • Page 72 DOOR UPPER TRIM PARTS REQUIRED: 2" (5 cm) 19/32 x 2-1/2 x 72" (3,2 x 6,3 x 182,9 cm) BEGIN Center ZJ on top of vertical trim. (Fig. A). Secure using 2" finish nails into framing as shown. 2" (5,1 cm) Finish Nails CENTER Flush...
  • Page 73 PAINT & CAULK - NOT INCLUDED - • Use acrylic latex caulk that is paintable. Caulk at all horizontal and vertical seams, between the trim and walls, and all around the door trim. • Use a high quality exterior acrylic latex paint. When painting your building, there are a few key areas that can be easily overlooked that must be painted: •...
  • Page 74 SHINGLES - NOT INCLUDED - • Follow directions provided by manufacturer and these instructions. Familiarize yourself with a 3-Tab Shingle. Notch Notch SHINGLE NAIL PATTERN 1/2" 1" Sealing Strip 1" (1,3 cm) (2,5 cm) (2,5 cm) Half A Rain Slot Full Rain Slot NAILS NEVER DRIVE FASTENERS INTO OR ABOVE SEALING STRIPS. BEGIN Install first starter row upside down and color up with a 1" overhang at back and bottom of roof panel. Use (4) nails per shingle. Starter row must be straight and level all the way across with lower edge of roof deck.
  • Page 75 SHINGLES continued... Beginning at front of shed, install first row of shingles with notch at 1" past roof edge or flush with drip edge. Roof Deck FRONT OF BACK OF SHED SHED 1" (2,5 cm) Flush with starter row. Notch - or - Drip Edge Flush with starter row.
  • Page 76 SHINGLES continued... Continue installing rows of shingles to the peak. At the peak make sure there is a maximum of 5" or less to the rain slot, as shown below. If shingles overlap at ridge cut to peak with a utility knife. 5"...
  • Page 77 SHINGLES - RIDGE CAP • You will finish off the top of the roof with a ridge cap made from shingles. BEGIN Cut shingles into THREE pieces. Hint: Use cut-off pieces first. 2" 2" (5 cm) (5 cm 2" 2" 2"...
  • Page 78 SHINGLES - RIDGE CAP continued... Continue installing ridge cap to back of roof. Make sure there is 4" between the shingle-color and edge of shingles. 4" (10 cm) Trim cap off flush to shingles When you have 4" minimum of shingle color cut one piece to cap your roof. Cut at top of rain slot.
  • Page 79 (This page intentionally left blank.)
  • Page 80 WARRANTY REGISTRATION Please complete your warranty registration to properly validate your warranty. Register your product online at:www.OnlineWarranty.net. LIMITED CONDITIONAL WARRANTY* Backyard Storage Solutions, LLC warrants the following: Every product is warranted from defects in workmanship and manufacturing for 1 year. All accessories, hardware and metal components are warranted for 2 years.
