Exmark MK443Q Installation Instructions Manual page 5

Loose Parts (For Serial Nos. 160,000–314,999,999)
Use the chart below to verify that all parts have been shipped.
Item Part No. Description
1 1-522487-03 Wld-Weldment LH 44
1-412263-03 Wld-Weldment LH 48
2 1-522489-03 Wld-Baffle RH 44
1-412265-03 Wld-Baffle RH 48
3 1-523473-01 Plate-Mulch Cover
4 103-2519 Blade, Mulch MK44 5/8 Hole
(black)
103-6390 Blade, Mulch MK44 15/16 Hole
(red)
103-6581 Blade, Mulch MK48 5/8 Hole
(black)
103-6391 Blade, Mulch MK48 15/16 Hole
(red)
*This item comes installed on mower deck and is not in kit.
Qty Item Part No.
1 1-522480-01
5*
1 1-402107-01
1 6 322-2
7
1 323-4
1 8 3230-1
3 9 32128-20
3 10 3290-357
3 11 1-653275-03
3
Figure 3
5
Description
Wld-Dogleg Baffle (MK443Q)
Wld-Dogleg Baffle (MK483Q)
Screw-HH 5/16-18 x 5/8
Screw-HH 3/8-16 x 3/4
Bolt-Carriage 5/16-18 x 3/4
Nut-Whizlock 5/16-18
Nut-Whizlock 3/8-16
Baffle-Blocker
Qty
1
1
3
3
5
8
3
1
g212001
