- Page 1 ThermoSpas® Genesis Series Owner’s Manual Safety, Maintenance and Technical Information...
- Page 2 Welcome to ThermoSpas Welcome To ThermoSpas Congratulations! You are now the official owner of the finest spa built. All of us at ThermoSpas are looking forward to enjoying a relationship with you that will last for many years to come.
-
Page 3: Table Of Contents
Website ........www.ThermoSpas.com... - Page 4 Programming Instructions ..................22 Programming the Duration, Frequency and Temperature Setting ..........22 Automatic Functions ...................23 Over-Temperature Protection ..................... 23 Power-Up Sequence ........................23 Smart Winter Mode........................23 Heating ............................23 Basic Spa Maintenance..................24 Changing/Cleaning Filters ..................26 Cleaning The Filter ........................26 Spas with ThermOzone ..................28 Components ..........................
- Page 5 Spa Measurements Chart ...................45 Water Capacity Chart ..................46...
-
Page 7: Read And Follow These Important Instructions
No. 6 AWG. Proper Use and Installation ThermoSpas has made every effort to provide you with a safe and reliable product. The detailed instructions provided previous to, and with the receipt of, your spa will explain how to safely in- stall, operate and maintain your spa. - Page 8 DANGER: RISK OF SEVERE INJURY FROM ELECTRIC SHOCK OR DEATH FROM ELECTROCUTION! • Install the spa at least 5 feet (1.5m), from all metal surfaces. As an alternative, a spa may be installed within 5 feet of metal surfaces if each metal surface is permanently connected (bonded) by a minimum No.
- Page 9 • Persons using medication should consult a physician before using a spa since some medication may induce drowsiness, while other medication may affect heart rate, blood pressure, and circulation. • Persons suffering from any condition requiring medical treatment, the elderly, or infants should consult with a physician before using a spa.
-
Page 10: Spa Safety Literature
Spa Safety Literature To ensure you have a safe and enjoyable spa experience, learn all you can about spa safety and emergency procedures. Especially useful are the brochures listed below: • Children Aren’t Waterproof • Pool and Spa Emergency Procedures For Infants and Children •... -
Page 11: Be Aware Of The Risk Of Fatal Hyperthermia
DANGER: RISK OF SEVERE INJURY OR DROWNING! Limb entrapment: May occur when a limb becomes entrapped, inserted or sucked into a suction or outlet opening. • Always keep suction fittings, suction covers, filter, filter lid or skimmer assembly in place when operating to avoid limb entrapment. -
Page 12: Choosing A Location
Site preparation, alterations to home owner’s property and permits (if any) are the sole responsi- bility of the owner. ThermoSpas spas are not intended for commercial applications. WARNING: For spas that are to rest on balconies, roofs or other platforms not specif- ically tied into main structural support, consult a professional Structural Engineer with experience in this type of application. -
Page 13: Indoor Location
• In the unlikely event that you should ever need to access or gain entry to any portion of the spa for servicing, it is highly recommended that you plan your outdoor installation to provide full access to the entire spa. Please take this into consideration when placing the spa in a deck or enclosed by a surrounding. - Page 14 Water damage to the home owner’s property from splashing or leaks are at the home owner’s risk. This is not covered under any ThermoSpas warranty. • Adequate ventilation must be provided in order to allow for chemical fumes to escape. Take into consideration that these fumes could enter other indoor areas.
-
Page 15: Electrical Set Up
Before beginning the wiring process turn off the circuit breaker so that no power is connected to the controller. ThermoSpas recommends all spa wiring to be done by a licensed electrician. Improper wiring may void your warranty. - Page 16 Electrical Service Considerations The Electrical Service determines how many pumps can run in conjunction with the heater. If the dedicated GFCI circuit was installed with a smaller breaker than the recommended size (typically 60 amps), your heater will automatically shut off to avoid tripping your circuit breaker if too many pumps are activated (including the blower).
- Page 17 120 VAC Alternate Hard Wired Electrical Connections for Gemini Genesis 100 Models If the supplied 10 ft GFCI power cord cannot reach a dedicated grounded wall outlet, it is neces- sary to install a 3-wire hard-wired connection. The diagram below illustrates that configuration. Sub Panel at Spa Main Panel Spa Pac...
- Page 18 240V Ground Fault Circuit Interrupt (GFCI) Wiring Diagram Sub Panel at Spa Main Panel Spa Pac Neutral/Ground Bar Neutral Bar Neutral Terminal block (White) inside of Pac White Pigtail Wire GFCI Load Neutral (White) Breaker Breaker See NOTE 3 Black Black Ground Green...
-
Page 19: Spa Start Up
Spa Start Up Please read through all steps before beginning. This section explains the necessary procedures required to start up your spa. Familiarize yourself with this procedure prior to beginning the pro- cess. Use this procedure as a guideline. • Make sure you have any Instructions along with the Welcome Kit and Chemical Starter Kit prior to filling your spa. - Page 20 Step 4: If your topside control panel display shows the temperature, the temperature flashing or “--”; this is normal. If any other codes are shown, refer to troubleshooting guide located in the appendix or visit http://online.ThermoSpas.com and click on Customer Center for more information.
- Page 21 Avoid using any biguanide or copper-based algaecide with your spa. Use of these prod- ucts is not recommended by ThermoSpas and may void your warranty. CAUTION: RISK OF PERSONAL INJURY OR SPA DAMAGE! Never add chlorine tablets (trichlor) or acid to your hot tub for any reason! These chem- icals may damage components within your hot tub, burn or irritate your skin, create a rash, and void the manufacturer warranty for your spa.
- Page 22 Improper water chemistry may cause skin irritation or facilitate the transmittal of disease. Proper water chemistry is the sole responsibility of the spa owner. The costs incurred from injury or damage resulting from improper water chemistry are not covered under the ThermoSpas, Inc. warranty.
-
Page 23: Spa Diagram
Spa Diagram The illustration below shows a typical spa with multiple jet styles, an ozone system upgrade and an independent filtration pump system. If your spa was not ordered with any of these features, the system components will not be found in your spa. These illustrations are designed to help you identify key components. -
Page 24: Equipment Diagram
Equipment Diagram The illustration below shows a typical equipment compartment. If your spa was not ordered with any of these features, the system components will not be found in your spa. These illustrations are designed to help you identify key components. Use the legend to locate a particular compo- nent. -
Page 25: Topside Control Panel
Topside Control Panel Main Control Panel Button Functions: Pump 1 Button: Press once to turn Pump 1 on low speed; a second time for high speed; a third time to turn off. Pump 2 Button (if equipped): Press once to turn Pump 2 on; press again to turn off. -
Page 26: Operating Instructions
Operating Instructions Setting the Temperature The LCD screen will constantly display the current water temperature, unless there is an error code or the spa needs attention. To set the desired water temperature: Figure 1 Press the Warm/Cool ( ) button, Figure 1. The current set temperature. Pressing the button a second time and any successive time will cause the set temperature to increase or decrease depending on what direction was last chosen. -
Page 27: Jets
Jets Therapy Jets Popular spa jets with powerful directional streams. These are easily controllable to give you just the right amount of massage. Turn the outer ring to open or close the jet to control the power. The nozzle can be adjusted by simply touching it and pointing it to the desired location on your body. -
Page 28: Programming Instructions
Programming Instructions Programming the Duration, Frequency and Temperature Setting Filter Cycles set the amount of time Pump 1 automatically operates in low speed to filter the spa water. The user can customize the duration and frequency of the filter cycles. At the beginning of the filter cycles, all pumps will activate to high speed for 1 minute to purge the plumbing lines of water, thus improving the overall cleanliness of the spa water. -
Page 29: Automatic Functions
Automatic Functions Over-Temperature Protection To prevent runaway heating of the spa, if the water exceeds 104°F the Filtration Cycles will be shortened to prevent excess heating of the water by pump 1 (minimum total filtration time per day will be 2 hours to maintain water cleanliness) until the water temperature decreases to the tem- perature set point. -
Page 30: Basic Spa Maintenance
Following the procedures below at the recommended intervals will insure that your spa provides years of service. If you have any questions concerning the maintenance of your spa please contact ThermoSpas’ Customer Care department. Cleaning and chemical products for your spa can be purchase at ThermoSpas’ online store at http://online.ThermoSpas.com. Item... - Page 31 The cover should be thoroughly cleaned and conditioned once a month using ThermoSpas Cover Conditioner. • Cleaning and Protecting the Cabinet. • Cabinets constructed of ThermoBoard require hosing and wiping down once or twice a year. Cleaning and chemical products for your spa can be purchase at ThermoSpas’ online store at http://online.ThermoSpas.com.
-
Page 32: Changing/Cleaning Filters
The skimmer/filter the Genesis Series can vary. To follow are the two distinct skimmer housing and the cleaning procedure for each. - Page 33 Cartridge Clean filter cartridge by first filling a bucket with water, adding 8 oz. of ThermoSpas Filter Clean. Mix solution by moving filter cartridge up and down several times. For best results, allow filter to soak for 12 to 24 hours (never less than 3).
-
Page 34: Spas With Thermozone
Spas with ThermOzone ThermOzone accomplishes water sanitation by using a powerful oxidant, Ozone. This 100% organic compound reacts with and destroys bacteria, mold, fungus, etc. Through a proprietary process, ozone effectiveness and air quality are maximized to provide optimal sanitation of your spa. -
Page 35: Drain And Refill
Note: You can use a submersible pump. Completely dry the shell surface with a soft, clean cloth. Clean the shell surface of any debris or mildew using ThermoGloss and ThermoSpas’ All Purpose Cleaner. Once you have completed all task above, make sure the drain valve is in the “OFF” position and reinstall the drain cap. -
Page 36: Cleaning The Cover
You should perform this procedure just before you drain your spa. We recommend using ThermoSpas Jet Line Cleaner to dissolve the build up of body oils, dirt, hair, soap, scum, rust and mineral deposits which are the perfect breeding ground for bacteria and mold. -
Page 37: Shell Surface Cleaning
The perfect product for cleaning the shell surface above the water line (when the spa is filled) is ThermoSpas All Purpose Cleaner. This helps to prevent a scum line from forming. Because it is a natural enzyme, it will not affect the water’s chemistry, it’s safe to use, it won’t scratch the acrylic, and it helps to eliminate mold or mildew odors without bleaching the surface. -
Page 38: Winterizing (Closing Your Spa)
Winterizing (Closing Your Spa) If you do not plan to use your spa during freezing weather, you will have to winterize it. Failure to winterize your spa will cause irreversible damage (in freezing temperatures) to the pump and plumbing lines. Winterization of your spa is easy. -
Page 39: Components
Components TO WATER JETS Water Pump “T” Valve Valve Lock Note: On some water pumps, Pump pipes heading to water jets Union may be located on the top of the pump. However, the configuration of the hose, “T” valve, remains the same. From Suction Pump Self Priming Hose... -
Page 40: Common Diagnostic Messages
An internal hardware error has does not clear, turn off the power to the spa been detected. and contact ThermoSpas Service Depart- ment 800.876.0158. Wait for the water to cool (you may add cold water) or turn off spa power, wait 30 DO NOT ENTER THE seconds, then turn on spa power. -
Page 41: Troubleshooting - Water Chemistry
Troubleshooting - Water Chemistry Problem Possible Cause Solution Cloudy Water • Dirty Filter • Clean filter with filter cleaner • High TDS Levels • Drain and refill with fresh • High pH or alkalinity water • Check and adjust using pH/ •... -
Page 42: Glossary
Glossary Activator (Potassium Monopersulfate) - Also known as non-chlorine shock, it is a strong oxi- dizer capable of eliminating contaminants from your spa. It is a non-chlorine chemical compound often used for shock treatments in spas. It is very popular for use in mineral purification systems. Algae - Algae may form on your spa surfaces or it may bloom in suspension. - Page 43 Copper - Copper in water is a common problem in many households. Copper is present due to the corrosion of plumbing materials from Acidic (low pH) or Aggressive water (low TDS). Com- mon problems associated with copper due corrosion are leaks in the plumbing system or blue- green staining.
- Page 44 Media - The selected materials in a filter that form the barrier to the passage of certain suspend- ed solids or dissolved molecules. Mineral Purification System (ThermoClear Cartridge) - Mineral cartridges are placed in your filter core and release silver and copper ions into the spa water. These ions kill bacteria and virus’s.
- Page 45 Safety Cover - A spa cover which meets strict ASTM standards for strength, construction, and anchoring, which reduces the drowning risk to small children. (Our covers are built to the ASTM safety standard). Not all hot tub covers on the market meet this important rating. Sanitize - Means to kill all bacteria, algae, disease-causing organisms, and any other uninvited guests.
- Page 46 Total Alkalinity - The ability of the spa water to resist changes in pH. The “buffering” capacity of the water. Additions of Sodium Bicarbonate will increase the levels, expressed in ppm. Additions of Sodium Bisulfate decrease Alkalinity levels. Acceptable measurements range from 80 – 120. Total Dissolved Solids (TDS) - Is a measurement of the total amount of minerals, residue, and other particles that cannot be oxidized from the water and remain.
- Page 47 Q: Can I change sanitizers? The use of ThermoClear and Chlorine can be used within the same spa water. All other sanitizers require the draining of the hot tub. We recommend the use of ThermoSpas’ Jet Line Cleaner for cleaning out the lines.
- Page 48 Q: What can I do if th pH is my spa is high (over 8.0) and will not come down? Follow the steps below. Turn on all pumps and add 1 ounce of ThermoSpas pH Down. Wait 15 minutes and retest the pH.
- Page 49 Q: How do I troubleshoot an instant tripping breaker? The proper way to troubleshoot is first turn GFCI breaker off. Access spa pack and unplug all components except for light. All water pumps, blowers, and ozonator if spa has one. Then turn GFCI breaker back on.
-
Page 50: Floor Load Determination
Floor Load Determination All structures must comply with local and national building requirements. The following recom- mended measurements represent maximum spans for decking floor joints (shown in feet and inches), assuming the following: • Modulus > 0.9 MM psi (represents the majority of wood species •... -
Page 51: Electrical Requirements Chart
Electrical Requirements Chart Model Voltage Breaker Size No. of Wires Wire Gauge Atlantis Genesis 200 240V 40A GFCI 4 Wire Atlantis Genesis 400 240V 50A GFCI 4 Wire Chesapeake Genesis 200 240V 40A GFCI 4 Wire Chesapeake Genesis 400 240V 50A GFCI 4 Wire Gemini Genesis 100... - Page 52 Water Capacity Chart Water Capacity Reference For Chemicals * Use approximate average fill for chemical measurement *Approximate Aver- Model age Fill 225 US gal. Atlantis Genesis 200 (851.6 Liters) 225 US gal. Atlantis Genesis 400 (851.6 Liters) 280 US gal. Chesapeake Genesis 200 (1,059.8 Liters) 280 US gal.
- Page 56 Designed to Improve Your Life 10 Research Parkway Suite 300 Wallingford, CT 06492 www.ThermoSpas.com SAVE THESE INSTRUCTIONS 6530-914 Rev C 01/28/2020...
