ASSEMBLY INSTRUCTIONS - PPLNNSTLRG
PARTS LIST
A. Leg
B. Middle Connector
C. Wood Countertop
D. Top Wood Table
E. Top Table Connector
F. Screw
G. Hex Key
H. Wood Screw
I. Screw Driver
A
B
C
D
E
F
X2
X1
X1
H
X1
X1
X6
Step 1. Assemble (2) Legs (A) with Middle Connec-
X1
tor (B) by fastening (2) screws (F) from both sides.
X14
Use Hex Key (G) provided within the package.
X1
Step 2. Flip over the assembled leg frame in Step 1,
and connect it to the bottom of the Wood Counter-
top (C) with (4) screws (F) as shown in picture below.
G
Step 3. Lay Top Wood Table (D) on a clean, smooth
surface (the side with pre-drilled holes facing up).
Align holes on Top Table Connector (E) with holes at
bottom of Wood Table-top. Insert and tighten (8)
I
Wood screws (H) using provided screw driver (I).
Step 4. Flip over the assembled parts in Step 3. Align
holes in Top Table Connector (F) with pre-drilled
holes on Wood Countertop (D).
Insert (3) Wood screws (H) on each mounting plate
on Top Table Connector. Tighten all Wood Screws
with the provided phillips screw driver (I).
