Led Display; Type Plate - SEH utnserver Pro Quick Installation Manual

LED Display

The LEDs of the UTN server provide information about its status.
LED Action
Link and permanently off –
Activity
Link permanently on
Activity blinks at
irregular
intervals
Status blinks 3 times
blinks 2 times
blinks 2 times
USB port permanently off
1–2
permanently on
permanently on
Important:
When the device starts up, the behavior of the LEDs
differs from this description.

Type Plate

The type plate gives important product information, such as hardware and
certification information as well as the serial number. The serial number
contains the production date: nnn YYYY MM nnnnn.
This information helps you e.g. during maintenance and is needed for support
requests.
4
Color Description
There is no connection to the network.
green There is a connection to the network.
yellow Indicates the exchange of UTN
packets.
green Indicates the assignment of a Zeroconf
IP address.
green Indicates the assignment of an IP
address that is not from the Zeroconf
range.
purple utnserver Pro operates with
elementary secure settings.
(HTTPs, no SNMPv1, restricted Control
Center access, encrypted USB
communication)
– No USB device is connected to the
respective port.
green A USB device is connected to the
respective port.
orange The connection to the respective port
and the attached USB device is
activated.
[en] Quick Installation Guide
