Technical Data

power supply
connector
(at the rear side)
status LED
(RGB)
Properties
Network connector
Device connection
Current input
Power consumption
Operating environment
Dimensions
Quick Installation Guide
1
USB ports 1-2
with LED for the USB port
Values
logical: IEEE 802.3 (1000BaseT, 100BaseTX and 10BaseT)
physical: 1 × RJ-45 (STP, category 5 or better)
• 2 × USB 3.0 SuperSpeed (USB ports 1–2)
• approx. 500 mA at 5 V direct current without load
• approx. 2500 mA at 5 V direct current with full
load on the USB ports
• approx. 3 W without load
• approx. 14 W with full load on the USB ports
• approx. 26–123 kWh/year, depending on
utilization
ambient temperature:
relative humidity:
width:
height:
depth:
weight:
network connector
(at the rear side)
activity LED
(yellow)
120 mm
30 mm
84 mm
125 g (without power supply unit)
[en]
(RJ-45)
link LED
(green)
2
5–40 °C
20–80 %
