- Page 1 PNOZ pps1p Safety relays Operating Manual 20675-EN-03...
- Page 2 Preface This document is a translation of the original document. All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made for internal purposes. Suggestions and comments for improving this documentation will be gratefully received.
-
Page 3: Table Of Contents
Use of qualified personnel Warranty and liability Disposal Unit features Block diagram Function Description Installation Wiring Preparing for operation Operation Status indicators Faults – Interference Dimensions in mm Technical details Order reference EC declaration of conformity Operating Manual PNOZ pps1p 20675-EN-03... -
Page 4: Introduction
PNOZ pps1p Introduction Validity of documentation This documentation is valid for the product PNOZ pps1p. It is valid until new documentation is published. This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product. -
Page 5: Safety
Safety Intended use The power supply unit PNOZ pps1p is intended for use in the modular safety system PNOZpower. It supplies base unit and expansion units with the required internal supply voltage. The following is deemed improper use in particular:... -
Page 6: Warranty And Liability
(e.g. Electrical and Electronic Equipment Act). Unit features Connection options for: – 1 base unit – Maximum 4 expansion modules LED indicator for: – Supply voltage – Output voltage Galvanic isolation Short circuit-proof Operating Manual PNOZ pps1p 20675-EN-03... -
Page 7: Block Diagram
Block diagram Function Description The power supply unit PNOZ pps1p supplies the base unit and the expansion modules of the modular safety system PNOZpower with the required supply voltage. When operating voltage is supplied the "POWER IN" LED will light. The "POWER OUT" LED will light when the output voltage is correct. - Page 8 PNOZ pps1p Only use terminators, jumpers and terminals of the modular safety system PNOZpower. Layout: – The power supply unit PNOZ pps1p can be installed in any position on the PNOZ- power modular safety system. Maximum hardware: – 1 base unit –...
-
Page 9: Wiring
Connect terminal to the protective earth system. When the PNOZ pps1p power supply unit is used, the base unit draws power via the PNOZpower bus. Do not connect an external supply voltage to terminals A1 and A2 of the base unit! Use copper wire that can withstand 60/75 °C. -
Page 10: Faults - Interference
19 V, 24 V Kind Output power 15 W Times Supply interruption before de-energisation 20 ms Environmental data Climatic suitability EN 60068-2-78 Ambient temperature Temperature range -10 - 55 °C Storage temperature Temperature range -40 - 85 °C Operating Manual PNOZ pps1p 20675-EN-03... - Page 11 TWIN crimp connectors 0,5 - 1,5 mm², Torque setting with screw terminals 0,5 Nm Dimensions Height 94 mm Width 45 mm Depth 121 mm Weight 285 g Where standards are undated, the 2014-07 latest editions shall apply. Operating Manual PNOZ pps1p 20675-EN-03...
-
Page 12: Order Reference
European Parliament and of the Council. The complete EC Declaration of Conformity is available on the Internet at www.pilz.com/support/downloads. Representative: Norbert Fröhlich, Pilz GmbH & Co. KG, Felix-Wankel-Str. 2, 73760 Ost- fildern, Germany Operating Manual PNOZ pps1p... - Page 13 Back cover Support Technical support is available from Pilz round the clock. Americas Australia Scandinavia Brazil +61 3 95446300 +45 74436332 +55 11 97569-2804 Spain Canada Europe +34 938497433 +1 888-315-PILZ (315-7459) Austria Switzerland Mexico +43 1 7986263-0 +41 62 88979-30...
