Pilot Communications Dr. Gripp 4+1 Instructions For Use

How to use
●Mechanical Pencil
（1）Slide the clip and the writing unit for the mechanical pencil
comes out, and is set in place.(Fig.1)
（2）Press the top of the clip to make the lead come out. (Fig.2)
（3）To retract the lead, press the lead back into the writing unit
while holding the top of the clip completely down.
（4）To retract the writing unit, slide other lever.
（5）Take the cap off to get the eraser.
※ For replacement eraser, please use PILOT HERFNS -10.
●Ball Point Pen
（1）Slide the lever of the colour you wish to use and the writing
tip comes out, and is set in place.
（2）To retract the writing tip, slide other lever.
How to refill a mechanical pencil with new leads
（1）Screw the barrel off.
（2）Hold the pen upwards and pull out the writing unit. (Fig.3)
（3）Insert leads up to three in total. (Fig.4)
※ Putting four or more leads may cause the guide pipe to clog.
（4）Firmly place the removed writing unit back in its original
position.
（5）Reassemble the pen by firmly screwing the barrel.
※ Please use PILOT leads (0.5mm).
Replacing a used ball point pen refill with new one
（1）Screw the barrel off.
（2）Pull the empty refill out.
（3）Insert a new refill completely into the refill holder.
（4）Reassemble the pen by firmly screwing the barrel.
※ Please use PILOT ball pen refill " BVRF-8 （Acro-ink） " for
Dr. GRIP4+1, " BKRF- 6F " for 4+1 LIGHT.

Remarks

● Do not use except for writing.
● Handle with care, as the point is sharp.
● Do not swallow the parts such as cap, eraser and
mouth piece.
● Keep away from children.
● To prevent ink leakage, never write with the pen point
upwards.
4colours Ball Point Pen
Available Colours:
(BLACK / RED / BLUE / GREEN )
Mechanical Pencil
( 0.5mm )
（Fig.1）
Barrel
Writing
Unit
（Fig.3）
● Avoid severe impact or violent shaking, as ink may
leak.
● Always retract the writing tips after use.
● The stains on the clothes may not wash off because
of permanent type of ink.
● Do not store in places exposed to direct sunshine or
high temperatures.
Instructions for Use
※ Please read before use
（Fig.2）
Leads
（Fig.4）
