MULTI-FUNCTIONS PEN
PILOT 2＋1, 3＋1 and 4＋1 Series-a combination of mechanical pencil and ballpoint pen, all in one. Total of 4 kinds of
PILOT 2＋1, 3＋1 and 4＋1 Series are available : Revolving type, Retractable & Twist type, Retractable & Button and
Lever Slide type.

Revolving (4 +1 . 3 +1 . 2 +1 )

How To Use The Ballpoint Pen
●
(1) Turn the upper barrel to make the tip come out.
(2) To retract the tip, turn the upper barrel to the
opposite direction.
How To Use The Mechanical Pencil
●
(1) Turn the upper barrel
pencil come out. Press the eraser cap to make the
lead come out.
(2) To retract the lead , press the lead onto the paper
while pushing the eraser cap down.
(3) To retract the writing unit to its original position,
turn the upper barrel anticlockwise.
(4) Unscrew the eraser cap off to use the eraser.
Retractable & Twist Type ( 3 +1 . 2 +1)

How to use the ballpoint pen

●
(1) While seeing the indication mark, press the eraser
cap and a tip of the colour of the indication mark
comes out.
(2) Twist the upper barrel to the right while holding the
lower barrel to retract the tip.

How to use the mechanical pencil

●
(1) While seeing the mechanical pencil mark , press
the eraser cap and the writing unit for the mechani-
cal pencil comes out. Then, press the eraser cap to
make the lead come out.
(2) Twist the upper barrel to the right while holding the
lower barrel to return the writing unit to its original
position, same as for the ballpoint pen.
(3) Unscrew the eraser cap off to use the eraser.
Retractable & Button Type ( 2 + 1 )
How to use the ballpoint pen
●
(1) While seeing the indication mark ( B or R ), press the
knob and a tip of the colour of the indication mark
comes out.
(2) To retract the writing tip, press the button on clip.
How to use the mechanical pencil
●
(1) While seeing the mechanical pencil mark , press
the knob and the writing unit for the mechanical
pencil comes out. Then, press the knob to make the
lead come out.
(2) To retract the lead, press the lead onto the paper
while pushing the knob down.
(3) To retract the writing unit, press the button on clip.
(4) Pull the knob to use the eraser.
to make the mechanical
Lower Barrel
2+1 (Mechanical pencil, Black ink ballpoint pen & Red ink ballpoint pen)
3+1 (Mechanical pencil, Black ink ballpoint pen, Red ink ballpoint pen & Blue ink ballpoint pen)
4+1 (Mechanical pencil, Black ink ballpoint pen, Red ink ballpoint pen, Blue ink ballpoint pen &
Green ink ballpoint pen)
Lower Barrel
How to use the ballpoint pen
Ref ill f or ballpoint pen
Mechanical pencil
W rit ing unit
How to use the ballpoint pen
ht t p: / / www. pi l ot . c o. j p/
Upper Barrel
Upper Barrel
Indicat ion mark
How to use the mechanical pencil
Clip
But t on
Barrel
Indication mark
0.5
B
How to use the mechanical pencil
Eraser Cap
Eraser Cap
0.5
Mechanical pencil
Red ink ballpoint pen
Black ink ballpoint pen
Blue ink ballpoint pen
knob
Mechanical pencil
R
Red ballpoint pen
Black ballpoint pen
