Instruction Manual Mi170 Bench Meter
www.milwaukeeinst.com
INSTRUCTION MANUAL
THANK YOU FOR CHOOSING
Bench Meter
Mi170
EC/TDS/NaCl/Temperature
Sales and Technical Service Contacts:
Milwaukee Electronics Kft.
Alsókikötõ sor 11.
H-6726 Szeged - HUNGARY
tel: +36 62 428 050
fax: +36 62 428 051
www: www.milwaukeeinst.com
e-mail: sales@milwaukeeinst.com
Milwaukee Instruments, Inc.
2950 Business Park Drive, Rocky Mount
NC 27804 USA
Tel: +1 252 443 3630
Fax: +1 252 443 1937
e-mail: sales@milwaukeetesters.com
www.milwaukeeinst.com
MANMI170
04/16
www.milwaukeeinst.com
32
1
Advertisement
Table of Contents
Related Manuals for Milwaukee Mi170
Summary of Contents for Milwaukee Mi170
- Page 1 Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com INSTRUCTION MANUAL THANK YOU FOR CHOOSING Bench Meter Mi170 EC/TDS/NaCl/Temperature Sales and Technical Service Contacts: Milwaukee Electronics Kft. Alsókikötõ sor 11. H-6726 Szeged - HUNGARY tel: +36 62 428 050 fax: +36 62 428 051 www: www.milwaukeeinst.com...
-
Page 2: Functional Description
PC INTERFACE ......................27 is not covered by the warranty. PROBE MAINTENANCE ................... 29 TROUBLESHOOTING ..................... 30 ACCESSORIES ......................30 Milwaukee Instruments reserves the right to make improvements in design, construction and appearance of its products without FUNCTIONAL DESCRIPTION advance notice. DISPLAY A. -
Page 3: Troubleshooting
Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com TROUBLESHOOTING FUNCTIONAL DESCRIPTION FRONT PANEL SYMPTOMS PROBLEM SOLUTION 1. Liquid Crystal Display (LCD) Reading fluctuates up and EC probe sleeve not properly Insert the sleeve. Tap the 2. CAL key, to enter/exit calibration down (noise). -
Page 4: General Description
The temperature coefficient is user selectable. Mi170 includes also GLP capability and data transfer to a computer through a RS232 or a USB port. In addition, the meter allows the user to enter an ID code to uniquely identify the instrument. -
Page 5: Specifications
Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com The instrument will answer for this command with: SPECIFICATIONS <STX> <answer> <ETX> where: <STX> is 02 ASCII code character (start of text) Range 0.00 to 29.99 µS/cm <ETX> is 03 ASCII code character (end of text) 30.0 to 299.9 µS/cm... - Page 6 Temp 2-point, at 0 and 50 °C (30 and 122 °F) To connect the instrument to a PC through the RS232 port, use the Milwaukee MA9350 Temperature Automatic or manual, from -20.0 to 120.0 °C (-4.0 to 248.0 °F) cable connector.
-
Page 7: Ec Solutions Temperature Dependence
%/°C. The reference temperature is displayed on the LCD for a few seconds and the instru- The following table lists the temperature dependence of Milwaukee EC calibration ment enters in the same range as it was at power off. -
Page 8: Temperature Calibration (For Technical Personnel Only)
No Compensation (NOTC): The temperature value is displayed, but is not taken For an accurate recalibration, contact your dealer or the nearest Milwaukee Customer into account and “°C” tag blinks. The reading displayed on the primary LCD is the Service Center, or follow the instructions bellow. - Page 9 Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com Notes: • If the reading is out of range, the full-scale value (100.0 for MTC/ATC mode or 400.0 for uncompensated TDS) will be displayed blinking. • If the SHIFT&RANGE/FIXED keys are pressed to freeze the LCD range and the reading goes out of range, the full-scale value of the frozen range will be displayed blink- ing.
-
Page 10: Ec/Tds Calibration
Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com SETUP EC/TDS CALIBRATION Setup mode allows viewing and modifying the following parameters: EC calibration is a one-point procedure. Selectable calibration points are 0.00 µS for offset and 84.0 µS, 1413 µS, 5.00 mS, 12.88 mS, 80.0 mS, 111.8 mS for slope. -
Page 11: Nacl Calibration
Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com • The temperature coefficient and compensation mode. Press the GLP/ACCEPT key to confirm calibration. The instrument stores the calibration value and returns to measurement mode. Notes: • If the uncalibrated reading is too far from the expected value, the “WRONG” and “SOLUTION”... - Page 12 Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com • For TDS range: the TDS factor. When the reading is stable, the “READY” and “ACCEPT” tags will blink on the LCD. Press the GLP/ACCEPT key to confirm calibration. The instrument stores the calibration value and returns to measurement mode.
-
Page 13: Good Laboratory Practice (Glp)
Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com • The date: month and day on the primary LCD and the year on the secondary LCD, GOOD LABORATORY PRACTICE (GLP) along with “DATE” tag. GLP is a set of functions that allows storage and retrieval of data regarding the main- tenance and status of the electrode. - Page 14 Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com Otherwise, the instrument will display the EC, TDS or NaCl value on the primary LCD • The EC calibration solution on the primary LCD and the cell constant on the sec- and the temperature on the secondary LCD, along with last stored record number ondary LCD.
- Page 15 Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com If there are less than 6 memory locations remaining, the record number and “Lo” message • The instrument ID. will blink to alert the user. LAST NaCl CALIBRATION DATA Last NaCl calibration data is stored automatically after a successful calibration. To view If the log space is full, “FULL LOC”...
- Page 16 Instruction Manual Mi170 Bench Meter www.milwaukeeinst.com • The temperature coefficient on the primary LCD, along with the temperature com- LOGGING pensation mode as in EC GLP mode. Up to 50 LOG samples can be stored into memory for each measurement range (EC, •...
