the card using new IP address. Repeat steps 4 to 12 to connect to the card and verify the IP
address if you cannot connect to the card, use a new IP address. Ping the idap card IP ad-
dress to verify the connection.
C. Program IP Address on idap Card Using dap4 Display Panel Keypad
Note: This procedure applies to dap4 controller with BIOS version 5.18 or later and idap card
with firmware version A1.5.0 B1.2.4 or later. dap4 BIOS version number can be viewed on
dap4 menu F - Information.
1. To program the IP address to the idap card using the dap4 display keypad, simply press and
hold the ALARM and ENTER keys simultaneously for one second, the following screen will
appear:
2. Use Select down key (i) to move the cursor to OTHER INFORMATION and press Enter.
This screen will appear:
3. Use Select down key (i) then Enter key to select PCOWEB/NET CONFIG, the following
screen will appear:
4. Press Enter key to select PCOWEB settings option. The following screen will appear:
5. Use Enter key to move the cursor then use the arrow keys to make change. If you select
DHCP ON, you cannot enter a static IP address. Select OFF on DHCP if you want to enter a
static address.
6. Press Select down key (i) to go to next page to enter NetMask and Gateway address then
go to the next page to enter DNS1 and DNS2 address if not, press Select down (i) key to go
to next page.
7. You may enter a BACnet device instance number if BACnet connection required otherwise
press Select down key (i) to go to the next page, the screen will appear:
8. Use Select down key (i) to select YES then press Enter key to confirm the change.
These screens will show:
Please wait for end of update
Then
Update complete-Reboot pCOnet to apply new settings
7
>SYSTEM INFORMATION
LOG DATA
OTHER INFORMATION
FLASH/ USB MEMORY
>ID NUMBER INFO
PCOWEB/NET CONFIG
MEMORIES STATUS
>PCOWEB settings
PCONET settings
DHCP: ON
IPAddress:
---.---.---.---
PCONET CONFIG ENABLE
Update pCOweb? NO
PCOweb CONFIG ENABLE
PCOweb CONFIG ENABLE
