Locations Functions
Power Switch:
Power on: Push once to power on the unit.
Shut down: Push and hold for 4 seconds to shut down.
12V power input interface (5.5*2.5): (new power supply voltage
input protection)
Connect the 12V 8A power adapter in the accessory box.
RESET switch: When you need to change the RAID mode, you need
to press this switch for a few second, and then create a new RAID
configuration mode.
Please refer to the setting method below for details.
RAID mode switch: RAID mode setting switch. See [RAID Mode
Comparison Table] for detailed settings.
USB3.0 interface: Use USB3.0 transmission cable to connect to
computer host, notebook, server, and other devices.
e-SATA interface: Use e-SATA transmission cable to connect to
computer host, notebook, server, and other devices.
Smart fan: When the hard disk is active, the fan will stay on. When
the hard disk goes into sleep mode, the fan will power down.
