Introduction
This 5.25" enclosure is designed to provide a solution to connect
existing storage devices such as 3.5" IDE hard drive, MO drives,
CD devices or DVD devices to USB2.0 or Firewire 1394a, an ideal
interconnect for multimedia application. This 5.25" enclosure can
provide peak data transfer rate up to 480Mbps for USB 2.0
interface and 400Mbps for Firewire 1394a interface.
Features
General
Support plug-n-play. Hot- Swap and Wake-UP.
Accommodate all existing storage devices such as 5.25" IDE
hard drives.
Support Self power mode.
Support Windows98. 98SE, ME, 2000 and XP operating
system.
USB 2.0 (For USB 2.0 & Combo version)
Compliant with Universal serial Bus Specification Revision
2.0
Compliant with ATA/ATAPI-6 Specification
Support LBA 48, PIO Mode 0-4, DMA Mode 0-2, UDMA Mode
0-5
Compliant with USB Mass Storage Bulk only Specification 1.0
Installation Manual
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Syba SY-UEN-5SL
Summary of Contents for Syba SY-UEN-5SL
- Page 1 Installation Manual Introduction This 5.25” enclosure is designed to provide a solution to connect existing storage devices such as 3.5” IDE hard drive, MO drives, CD devices or DVD devices to USB2.0 or Firewire 1394a, an ideal interconnect for multimedia application. This 5.25” enclosure can provide peak data transfer rate up to 480Mbps for USB 2.0 interface and 400Mbps for Firewire 1394a interface.
- Page 2 Support High-Speed (480Mbps) and Full-Speed (12Mbps) mode Firewire IEEE1394a (Combo version) Compliant with IEEE1394-1995 and 1394a standard for high performance serial bus Sustained IDE rate at 25Mbytes/sec (200Mbps), Peak transfer rate at 50Mbytes/sec (400Mbps) Compliant with ATA/ATAPI-6 Specification Support PIO Mode 0-4, DMA mode 0-2, UDMA mode 0-5 Support SBP-2 and ATA/ATAPI Protocols What is in your package? Please check whether the package contains following items:...
-
Page 3: Hardware Installation
soon as possible. Notice: For all existing storage devices such as 3.5’’ IDE hard drives, please make sure the JUMPER setting set to MASTER before installing into 5.25” Enclosure. (However, for certain hard drives, you may need to set the jumper as “Cable Select”.) HARDWARE INSTALLATION Installing a CD/DVD devices into the 5.25’’... - Page 4 Slide the CD/DVD device into the front Step 3: Align CD/DVD device and secure it with the screw provided Step 4:...
- Page 5 1) Connect the power connector to CD/DVD device 2) Connect the IDE cable to CD/DVD device 3) Connect the audio cable to CD/DVD device Step 5: Fold the cables and close back the rear cover. Secure the rear cover with the screw provided.
- Page 6 Installing a 3.5” hard drive into the 5.25’’ enclosure Step 1: Slowly remove the rear cover Step 2: Close the front bay with cover provided...
- Page 7 Step 3: Hold the hard drive and align into the enclosure Step 4: Align the hard drive and secure it with the screw provided...
- Page 8 Step 5: 1) Connect the power connector to hard drive 2) Connect the IDE cable to hard drive 3) Connect the RED LED cable to “ P4 “ 4) Connect the GREEN LED cable to “ P3 “ Step 6: Fold the cables and close back the rear cover.
-
Page 9: Software Installation
After securing the CD/DVD device or hard drive, you can cover the screw or screw hole using the rubber sheet provided. Connect the appropriate cables to the 5.25” enclosure. Make sure the polarity of the AC-DC 12VDC power supply is correct. If the polarity is not correct, you can damage the electronic section of the 5.25”... - Page 10 No need for additional drivers because Microsoft already provides an USB Mass Storage driver with Windows ME, 2000& XP operating system. Once you connect the 5.25” enclosure to the USB 2.0 port on your system, Windows should automatically detect the device and install the appropriate drivers. B.
